Case Reports
. 2002 Aug;23(7):1153-5.

Superior petrosal sinus catheterization for transvenous embolization of a dural carotid cavernous sinus fistula

Charbel Mounayer  1 , Michel Piotin, Laurent Spelle, Jacques Moret
Affiliations
Case Reports

Superior petrosal sinus catheterization for transvenous embolization of a dural carotid cavernous sinus fistula

Charbel Mounayer et al. AJNR Am J Neuroradiol. 2002 Aug.

Abstract

We report the endovascular treatment of a dural carotid cavernous fistula in a 67-year-old woman in whom superior petrosal sinus catheterization was performed to access the venous site of the fistula. To our knowledge, this retrograde venous route via the superior petrosal sinus has not been previously described.

PubMed Disclaimer

Figures

F<sc>ig</sc> 1.
Fig 1.
Lateral angiograms. A, Arterial-phase right internal carotid arteriogram shows the DCCF at the right posterosuperior aspect of the CS (solid arrow) fed by dural branches of the carotid siphon. The right trigeminal vein (open arrow) is draining the DCCF. B, Right external carotid arteriogram shows that the DCCF is draining into the right superficial middle cerebral vein (arrowheads), the right SOV (solid arrow), and the right trigeminal vein (open arrow).
F<sc>ig</sc> 2.
Fig 2.
Venous-phase lateral left common carotid arteriogram. The most distal aspect of the right SPS is faintly opacified as it merges with the right transverse sinus (arrow)
F<sc>ig</sc> 3.
Fig 3.
Frontal skull radiographic image shows retrograde catheterization of the right SPS via a right internal jugular route. A 5F hydrophilic catheter (arrow) is positioned into the distal end of the right SPS by means of a right jugular approach. A microcatheter (arrowhead) is coaxially introduced into the 5F catheter and navigated into the SPS to reach the CS
F<sc>ig</sc> 4.
Fig 4.
Right common carotid control angiogram obtained at the end of the embolization procedure shows that the DCCF is no more opacified than before and during the procedure.
See this image and copyright information in PMC

References

    1. Brown RD Jr, Wiebers DO, Nichols DA. Intracranial dural arteriovenous fistulae: angiographic predictors of intracranial hemorrhage and clinical outcome in nonsurgical patients. J Neurosurg 1994;81:531–538 - PubMed
    1. Halbach VV, Higashida RT, Hieshima GB, Reicher M, Norman D, Newton TH. Dural fistulas involving the cavernous sinus: results of treatment in 30 patients. Radiology 1987;163:437–442 - PubMed
    1. Lucas CP, Zabramski JM, Spetzler RF, Jacobowitz R. Treatment for intracranial dural arteriovenous malformations: a meta-analysis from the English language literature. Neurosurgery 1997;40:1119–1130 - PubMed
    1. Roy D, Raymond J. The role of transvenous embolization in the treatment of intracranial dural arteriovenous fistulas. Neurosurgery 1997;40:1133–1141 - PubMed
    1. Yamashita K, Taki W, Nishi S, et al. Transvenous embolization of dural caroticocavernous fistulae: technical considerations. Neuroradiology 1993;35:475–479 - PubMed
