A new approach yields high rates of radiographic progression in knee osteoarthritis

Abstract

Objective: Progression of knee osteoarthritis (OA) has typically been assessed in the medial tibiofemoral (TF) compartment on the anteroposterior (AP) or posteroanterior (PA) view. We propose a new approach using multiple views and compartments that is likely to be more sensitive to change and reveals progression throughout the knee.

Methods: We tested our approach in the Multicenter Osteoarthritis Study, a study of persons with OA or at high risk of disease. At baseline and 30 months, subjects provided PA (fixed flexion without fluoro) and lateral weight-bearing knee radiographs. Paired radiographs were read by 2 readers who scored joint space (JS) using a 0-3 atlas-based scale. When JS narrowed but narrowing did not reach a full grade on the scale, readers used half-grades. Change was scored in medial and lateral TF compartments on both PA and lateral views and in the patellofemoral (PF) joint on lateral view. A knee showed progression when there was at least a half-grade worsening in JS width in any compartment at followup. Disagreements were adjudicated by a panel of 3 readers. To validate progression, we tested definitions for TF progression to see if malalignment on long-limb radiographs at baseline (>or=3 degrees malaligned in any direction with nonmalaligned knees being reference) increased risk of progression. A valid definition of progression would show that malalignment strongly predicted progression.

Results: We studied 842 knees with either Kellgren-Lawrence grade>or=2 or PF OA at baseline in 606 subjects (age range 50-79 yrs, mean 63.9 yrs; 66.6% women). Mean body mass index was 31.9, and 32.8% of knees had frequent knee pain at baseline. Of these, 500 knees (59.4%) showed progression. Of the 500, 75 (15%) had progression only in the PF joint, while the remainder had progression in the TF joint. Malalignment increased the risk of overall progression in TF joint and increased the risk of half-grade progression, suggesting that half-grade progression had validity.

Conclusion: PA and lateral views obtained in persons at high risk of OA progression can produce a cumulative incidence of progression above 50% at 30 months. Keys to increasing the yield include imaging PF and lateral compartments, using semiquantitative scales designed to detect change, and examining more than one radiographic view.

Figure 1

Examples of half-grade radiographic changes seen on posteroanterior lateral view. A: the baseline radiograph; B: the followup radiograph.

Figure 2

Examples of half-grade radiographic changes seen in the tibiofemoral compartment. A: the baseline radiograph; B: the followup radiograph.

Figure 3

Examples of half-grade radiographic changes seen on lateral view in the patellofemoral joint. A: the baseline radiograph; B: the followup radiograph.

Figure 4

Where is progression? Left: a depiction of tibiofemoral (TF) compared to patellofemoral (PF) compartment as a source of progression. Top panel: TF progression in posteroanterior (PA) view versus lateral view versus both. Middle panel shows which TF compartment showed progression. Bottom panel shows the percentage of half-grade versus full-grade TF progression.
