Clinical Trial
. 2011 Oct;20(10):1711-9.
doi: 10.1007/s00586-011-1801-y. Epub 2011 Apr 28.

Assessment of two novel surgical positions for the reduction of scoliotic deformities: lateral leg displacement and hip torsion

Christopher Driscoll  1 , Carl-Eric Aubin, Hubert Labelle, Jean Dansereau
Affiliations
Clinical Trial

Assessment of two novel surgical positions for the reduction of scoliotic deformities: lateral leg displacement and hip torsion

Christopher Driscoll et al. Eur Spine J. 2011 Oct.

Abstract

Cobb angles and apical vertebral rotations (AVR) are two of the main scoliosis deformity parameters which spinal instrumentation and fusion techniques aim to reduce. Despite this importance, current surgical positioning techniques do not allow the reduction of these parameters. Two new surgical frame accessory prototypes have been developed: (1) a lateral leg displacer (LLD) allows lateral bending of a patient's legs up to 75° in either direction and (2) a pelvic torsion device (PTD) which allows transverse plane twisting of a patient's pelvis at 30° in either direction while raising the thoracic cushion, opposite to the raised side of the pelvis, by 5 cm. The objective of this study was to evaluate the ability of the LLD and PTD to reduce Cobb angles and AVR. Experimental testing was performed pre-operatively on 12 surgical scoliosis patients prone on an experimental surgical frame. Postero-anterior radiographs of their spines were taken in the neutral prone position on a surgical frame, and then again for 6 with their legs bent towards the convexity of their lowest structural curve, 4 with their pelvis raised on the convex side of their lowest structural curve and one each in opposite LLD and PTD intended use. Use of the LLD allowed for an average supplementary reduction of 16° (39%) for Cobb angle and 9° (33%) for AVR in the lowest structural curve. Use of the PTD allowed for an average supplementary reduction of 9° (19%) for Cobb angle and 17° (48%) for AVR in the lowest structural curve. Both devices were most efficient on thoraco-lumbar/lumbar curves. Opposite of intended use resulted in an increase in both Cobb angle and AVR. The LLD and PTD provide interesting novel methods to reduce Cobb angles and AVR through surgical positioning which can be used to facilitate instrumentation procedures by offering an improved intra-operative geometry of the spine.

PubMed Disclaimer

Figures

Fig. 1
Fig. 1
a Lateral leg displacer (LLD) with subject; b, c pelvic torsion device (PTD) with and without subject
Fig. 2
Fig. 2
Direction of lower limb lateral displacement and pelvic torsion/thoracic cushion vertical displacement depending on location of lowest structural scoliotic curve
Fig. 3
Fig. 3
Radiographs of patients 1–6 and 11 in the neutral prone (top row) and laterally bent leg (bottom row) positions. Arrow direction of lower limb displacement
Fig. 4
Fig. 4
Radiographs of patients 7–10 and 12 in the neutral prone (1st and 2nd row) and twisted pelvis positions (3rd and 4th row). Arrow direction of pelvic torsion
See this image and copyright information in PMC

References

    1. Delorme S, Labelle H, Poitras B, Rivard CH, Coillard C, Dansereau J. Pre-, intra-, and postoperative three-dimensional evaluation of adolescent idiopathic scoliosis. J Spinal Disord. 2000;13(2):93–101. doi: 10.1097/00002517-200004000-00001. - DOI - PubMed
    1. Behairy YM, Hauser DL, Hill D, Mahood J, Moreau M. Partial correction of Cobb angle prior to posterior spinal instrumentation. Ann Saudi Med. 2000;20(5–6):398–401. - PubMed
    1. Driscoll CR, Aubin CE, Canet F, Labelle H, Dansereau J (2011) Impact of prone surgical positioning on the scoliotic spine. J Spinal Disord Tech. 2011 Mar 16. [Epub ahead of print] - PubMed
    1. Lee SM, Suk SI, Chung ER. Direct vertebral rotation: a new technique of three-dimensional deformity correction with segmental pedicle screw fixation in adolescent idiopathic scoliosis. Spine (Phila Pa 1976) 2004;29:343–349. doi: 10.1097/01.BRS.0000109991.88149.19. - DOI - PubMed
    1. Rinella A, Lenke L, Whitaker C, Kim Y, Park SS, Park SS, Peelle M, Edwards C, 2nd, Bridwell K. Perioperative halo-gravity traction in the treatment of severe scoliosis and kyphosis. Spine (Phila Pa 1976) 2005;30(4):475–482. doi: 10.1097/01.brs.0000153707.80497.a2. - DOI - PubMed
