Two Cases of Enlarged Zuckerkandl's Tubercle of the Thyroid Displacing the Recurrent Laryngeal Nerve Laterally

Emin Gurleyik  1
Affiliations
Case Reports

Two Cases of Enlarged Zuckerkandl's Tubercle of the Thyroid Displacing the Recurrent Laryngeal Nerve Laterally

Emin Gurleyik. Case Rep Med. 2011.

Abstract

The thyroid has many anatomic variations. Zuckerkandl's tubercle (ZT) is the posterior extension of lateral lobes. ZT has a relation with the recurrent laryngeal nerve (RLN). RLN lateral to ZT is an uncommon occurrence. This paper presents two cases of this uncommon situation. A 60-year-old female patient with large multinodular goiter was treated with total thyroidectomy. A 69-year-old male patient with follicular neoplasm was treated with total lobectomy. The inferior thyroid arteries and the recurrent laryngeal nerves were identified with usual lateral approach. A left ZT was found in case 1 and a right ZT in case 2. Distal parts of the RLNs were displaced laterally by enlarged ZTs in both cases. Grade 3 ZTs composed of thyroid tissue were placed between the trachea and the RLNs. The ZT is a common anatomic feature of the thyroid. Close relation of the tubercle with the RLN is an important surgical entity. The enlarged ZT seldom pushes the nerve laterally. The knowledge of the anatomy of ZT and its relation with the RLN including all variations is mandatory for safe thyroid operations.

PubMed Disclaimer

Figures

Figure 1
Figure 1
Enlarged tubercle of Zuckerkandl (Case 1) placed between the trachea and the left RLN. The distal part of the RLN was displaced laterally.
Figure 2
Figure 2
A grade 3 Zuckerkandl's tubercle (Case 2) displaced the right RLN laterally.
Figure 3
Figure 3
After freeing the tubercle of Zuckerkandl and Berry ligament, the RLN returned back to its usual position in trachea-esophageal groove.
See this image and copyright information in PMC

References

    1. Shoja MM, Tubbs RS, Loukas M, Shokouhi G, Jerry Oakes W. Emil Zuckerkandl (1849–1910): anatomist and pathologist. Annals of Anatomy. 2008;190(1):33–36. - PubMed
    1. Costanzo M, Caruso LA, Veroux M, Messina DC, Marziani A, Cannizzaro MA. The lobe of Zuckerkandl: an important sign of recurrent laryngeal nerve. Annali Italiani di Chirurgia. 2005;76(4):337–340. - PubMed
    1. Hisham AN, Lukman MR. Recurrent laryngeal nerve in thyroid surgery: a critical appraisal. ANZ Journal of Surgery. 2002;72(12):887–889. - PubMed
    1. Delbridge L. Total thyroidectomy: the evolution of surgical technique. ANZ Journal of Surgery. 2003;73(9):761–768. - PubMed
    1. Page C, Cuvelier P, Biet A, Boute P, Laude M, Strunski V. Thyroid tubercle of Zuckerkandl: anatomical and surgical experience from 79 thyroidectomies. Journal of Laryngology and Otology. 2009;123(7):768–771. - PubMed
