Sperm structure and motility in the eusocial naked mole-rat, Heterocephalus glaber: a case of degenerative orthogenesis in the absence of sperm competition?

Abstract

Background: We have studied sperm structure and motility in a eusocial rodent where reproduction is typically restricted to a single male and behaviourally dominant queen. Males rarely compete for access to the queen during her estrus cycle, suggesting little or no role for sperm competition.

Results: Our results revealed an atypical mammalian sperm structure with spermatozoa from breeding, subordinate and disperser males being degenerate and almost completely lacking a "mammalian phylogenetic stamp". Sperm structure is characterized by extreme polymorphism with most spermatozoa classified as abnormal. Sperm head shapes include round, oval, elongated, lobed, asymmetrical and amorphous. At the ultrastructural level, the sperm head contains condensed to granular chromatin with large open spaces between the chromatin. Nuclear chromatin seems disorganized since chromatin condensation is irregular and extremely inconsistent. The acrosome forms a cap (ca 35%) over the anterior part of the head. A well defined nuclear fossa and neck with five minor sets of banded protein structures are present. The midpiece is poorly organized and contains only 5 to 7 round to oval mitochondria. The flagellar pattern is 9+9+2. A distinct degenerative feature of the tail principal piece is the absence of the fibrous sheath. Only 7% motile spermatozoa were observed which had exceptionally slow swimming speeds.

Conclusion: In this species, sperm form has simplified and degenerated in many aspects and represents a specialised form of degenerative orthogenesis at the cellular level.

Figure 1

Bright field microscopy of naked mole-rat spermatozoa stained with SpermBlue and showing evident sperm polymorphism. a) normal spermatozoon; b) compressed head; c) lobed head and curled tail; d) cone-shaped head; e) double macro-heads; f-h) multi-lobed elongated heads; g) head without acrosome; i) micro-head; j) amorphous head; k) apparent nuclear vacuoles representative of fragmentation. MP = midpiece, ACR = acrosome.

Figure 2

Scanning and transmission electron micrographs of naked mole-rat spermatozoa. a) Scanning electron micrograph of a typical multi-lobed sperm head, b-h) Transmission electron micrographs of naked mole-rat spermatozoa sectioned in different planes: b) Longitudinal section almost similar to spermaozoon in (a) showing irregular arranged chromatin, small midpiece and thin tail; c) Two sperm heads showing severe fragmentation and small midpiece; d) Sperm head containing a simple acrosomal cap; d-e) Proximal centriole with capitulum and striations of cross banded structures; f) Transverse to oblique section of anterior part of midpiece showing mitochondria with tubular-like cristae, some cross banded structures and distal centriole; g) Axoneme (9+2 microtubules) surrounded by nine outer dense fibres in midpiece; h) Only axonome in tail principal piece without a fibrous sheath. ACR = acrosome, HEAD = sperm head, FRG = fragmented sperm head, CAP = capitulum, PC = proximal centriole, CBS = cross banded structures, DC = distal centriole, MIT = mitochondria, MP = midpiece. Scale bars: a, b, c = 1 μm; d, e, f = 0.5 μm; g, h = 0.25 μm.

Figure 3

Three representative sperm motility patterns of naked mole-rat spermatozoa recorded at 50 frames/second. Red line = VCL, blue line = VSL and green line = VAP. The kinematic data for each track is shown on its immediate right (cut off values based on VCL (μm/s) = Fast > 45 > Medium > 35 Slow). VCL = curvilinear velocity, VSL = straight-line velocity, VAP = average path velocity, LIN = linearity, STR = straightness, WOB = wobble, ALH = amplitude of lateral head displacement, BCF = beat cross frequency.
