Comparative Study
. 2012 May 1;17(3):e457-61.
doi: 10.4317/medoral.17599.

Osteotomy in direct sinus lift. A comparative study of the rotary technique and ultrasound

María Peñarrocha-Diago  1 , Miguel Peñarrocha-Diago, Cristina Sanchez-Recio, David Peñarrocha-Oltra, Javier Romero-Millán
Affiliations
Comparative Study

Osteotomy in direct sinus lift. A comparative study of the rotary technique and ultrasound

María Peñarrocha-Diago et al. Med Oral Patol Oral Cir Bucal. .

Abstract

Purpose: The present study investigates sinus membrane rupture in direct maxillary sinus lift with the rotary technique and with ultrasound, examining the survival of implants placed after sinus augmentation, and analyzing the bone gain obtained after the operation and 12 months after placement of the prosthetic restoration.

Materials and methods: A retrospective study was made of 45 patients requiring maxillary sinus lift or augmentation for implant-prosthetic rehabilitation. Use was made of the handpiece and ostectomy drills for the rotary technique, and of specific tips for ultrasound. The implant success criteria were based on those developed by Buser. The bone gain obtained as a result of sinus lift was calculated from the postoperative panoramic X-rays.

Results: A total of 57 direct elevations of the maxillary sinus were carried out: 32 with the rotary technique and 25 with ultrasound. Perforations of Schneider's membrane with the rotary technique and ultrasound occurred in 7% and 1.7% of the cases, respectively, with membrane integrity being preserved in 91.2%. Of the 100 implants placed, 5 failed after one year of follow-up in the rotary technique group, while one implant failed in the ultrasound group. The rotary technique in turn afforded a bone gain of 5.9 mm, versus 6.7 mm with ultrasound.

Conclusions: Perforations of the membrane sinusal in direct lift were more frequent with the rotary technique (7%) than with ultrasound (1.7%). Implant survival and bone gain were both greater when ultrasound was used.

PubMed Disclaimer

Figures

Figure 1
Figure 1
Preoperative panoramic X-ray view.
Figure 2
Figure 2
Postoperative panoramic X-ray view.
Figure 3
Figure 3
Postoperative panoramic X-ray view. Measurement of bone gain. A. Length of the implant. B. Occlusal line of the alveolar crest. C. Lower margin of the maxillary sinus before grafting. a. Radiological alveolar crest height before grafting. D. Lower margin of the maxillary sinus after grafting. b. Radiological alveolar crest height after grafting. Note the increase in height at the level of each of the implants. c. The bone gain (in green) is obtained by subtracting the radiological alveolar crest height before grafting from the height after grafting (c=b-a).
Figure 4
Figure 4
Postoperative panoramic X-ray view. Measurement of bone loss after prosthetic loading.
