. 2013 Mar-Apr;79(2):158-62.
doi: 10.5935/1808-8694.20130028.

Cochlear implantation through the middle cranial fossa: a novel approach to access the basal turn of the cochlea

[Article in English, Portuguese]
Aline Gomes Bittencourt  1 , Robinson Koji Tsuji, João Paulo Ratto Tempestini, Alfredo Luiz Jacomo, Ricardo Ferreira Bento, Rubens de Brito
Affiliations

Cochlear implantation through the middle cranial fossa: a novel approach to access the basal turn of the cochlea

[Article in English, Portuguese]
Aline Gomes Bittencourt et al. Braz J Otorhinolaryngol. 2013 Mar-Apr.

Abstract

The classic approach for cochlear implant surgery includes mastoidectomy and posterior tympanotomy. The middle cranial fossa approach is a proven alternative, but it has been used only sporadically and inconsistently in cochlear implantation.

Objective: To describe a new approach to expose the basal turn of the cochlea in cochlear implant surgery through the middle cranial fossa.

Method: Fifty temporal bones were dissected in this anatomic study of the temporal bone. Cochleostomies were performed through the middle cranial fossa approach in the most superficial portion of the basal turn of the cochlea, using the meatal plane and the superior petrous sinus as landmarks. The lateral wall of the internal acoustic canal was dissected after the petrous apex had been drilled and stripped. The dissected wall of the inner acoustic canal was followed longitudinally to the cochleostomy.

Results: Only the superficial portion of the basal turn of the cochlea was opened in the fifty temporal bones included in this study. The exposure of the basal turn of the cochlea allowed the visualization of the scala tympani and the scala vestibuli, which enabled the array to be easily inserted through the scala tympani.

Conclusion: The proposed approach is simple to use and provides sufficient exposure of the basal turn of the cochlea.

PubMed Disclaimer

Figures

Figure 1
Figure 1
Anatomy of the middle cranial fossa. ME: Middle ear; AE: Arcuate eminence; SPS: Superior petrosal sinus; GSPN: Greater superficial petrosal nerve; MP: Meatal plane; BTC: Basal turn of the cochlea; PA: Petrous apex; MMA: Middle meningeal artery.
Figure 2
Figure 2
Anatomy of the middle cranial fossa viewed perpendicularly from the petrous. AE: Arcuate eminence; SPS: Superior petrosal sinus; GSPN: Greater superficial petrosal nerve; PA: Petrous apex. DM: Dura mater of the middle cranial fossa; MMA: Middle meningeal artery.
Figure 3
Figure 3
A-B: Right temporal bone high-resolution CT scan. Coronal view, bone window, showing the placement of the array from the basal (A) to the apical (B) turn of the cochlea.
Figure 4
Figure 4
Right temporal bone high-resolution CT scan. Axial view, bone window, showing the placement of the array from the basal to the apical turn of the cochlea.
Figure 5
Figure 5
Right temporal bone high-resolution CT scan. 3D reconstruction showing the placement of the CI array through the middle cranial fossa.
See this image and copyright information in PMC

Similar articles

See all similar articles

Cited by

References

    1. El-Kashlan HK, Arts HA, Telian SA. External auditory canal closure in cochlear implant surgery. Otol Neurotol. 2003;24(3):404–408. - PubMed
    1. Ramsden RT, Wheatley H. Developing surgical techniques in cochlear implantation. Cochlear Implants Int. 2000;1(2):67–81. - PubMed
    1. Colletti V, Fiorino FG. New window for cochlear implant insertion. Acta Otolaryngol. 1999;119(2):214–218. - PubMed
    1. Leung R, Briggs RJ. Indications for and outcomes of mastoid obliteration in cochlear implantation. Otol Neurotol. 2007;28(3):330–334. - PubMed
    1. Basavaraj S, Shanks M, Sivaji N, Allen AA. Cochlear implantation and management of chronic suppurative otitis media: single stage procedure? Eur Arch Otorhinolaryngol. 2005;262(10):852–855. - PubMed
