. 2014 May;38(5):1083-9.
doi: 10.1007/s00264-013-2165-1. Epub 2013 Nov 19.

Influence of cyclical mechanical loading on osteogenic markers in an osteoblast-fibroblast co-culture in vitro: tendon-to-bone interface in anterior cruciate ligament reconstruction

Johannes Struewer  1 , Philip P Roessler, Karl F Schuettler, Volker Ruppert, Thomas Stein, Nina Timmesfeld, Juergen R J Paletta, Turgay Efe
Affiliations

Influence of cyclical mechanical loading on osteogenic markers in an osteoblast-fibroblast co-culture in vitro: tendon-to-bone interface in anterior cruciate ligament reconstruction

Johannes Struewer et al. Int Orthop. 2014 May.

Abstract

Purpose: We aimed to evaluate the influence of cyclical mechanical loading on osteoblasts and fibroblasts, and co-cultures of both in vitro, simulating the conditions of the tendon-to-bone interface in anterior cruciate ligament reconstruction.

Methods: Osteoblast-like cells (OBL) and tendon-derived rodent fibroblasts (TDF) were cultured alone or in co-culture to simulate the tendon-to-bone interface. Cyclical loading was applied for one hour twice a day for three days, with a frequency of 1 Hz and 3 % strain. Alkaline phosphatase (AP), osteocalcin (OC), collagen type 1 (COL1A1), and bone morphogenetic protein 2 (BMP-2) gene expression and protein deposition were detected by real-time polymerase chain reaction (qPCR) and immunocytochemical analysis.

Results: Mechanical loading significantly decreased AP, OC, and COL1A1 gene expression in both OBL and TDF, compared to non-loaded culture. However, mechanical load increased gene expression of the same marker genes including BMP-2 during co-culture. Immunocytochemistry demonstrated increased deposition of corresponding proteins in the same range, independent of culture conditions. Higher depositions of BMP-2 were shown under loading conditions for osteoblast and TDF monocultures. Prolongation of mechanical loading resulted in cell detachment and spheroid formation.

Conclusion: Cyclical mechanical loading caused downregulation of genes involved in osteointegration and osteoinduction, such as OC, ALP, and COL1A1 in monocultures of osteoblasts and fibroblasts; co-cultures lacked this phenomenon. Immunocytochemistry and qPCR analysis showed slight upregulations of marker genes and corresponding proteins. This might be due to the potential stabilising effects of osteoblast-fibroblast cross talk in the co-culture environment, simulating fibrocartilage formation at the tendon-to-bone interface.

PubMed Disclaimer

Figures

Fig. 1
Fig. 1
Influence of cyclical mechanical loading on all three culture types on BMP-2 deposition as detected by immunocytochemistry (10× magnification). a Osteoblast-like cells. b Fibroblasts. c Co-culture
Fig. 2
Fig. 2
Influence of prolonged continuous mechanical loading on all three culture types, for one or three days, on BMP-2 deposition as detected by immunocytochemistry. Significant detachment of cells from collagen-coated surfaces were found in all specimens (10× magnification). a Osteoblast-like cells. b Fibroblasts. c Co-culture
See this image and copyright information in PMC

References

    1. Biau DJ, Katsahian S, Kartus J, Harilainen A, Feller JA, Sajovic M, Ejerhed L, Zaffagnini S, Ropke M, Nizard R. Patellar tendon versus hamstring tendon autografts for reconstructing the anterior cruciate ligament: a meta-analysis based on individual patient data. Am J Sports Med. 2009;37(12):2470–2478. doi: 10.1177/0363546509333006. - DOI - PubMed
    1. van Eck CF, Schreiber VM, Mejia HA, Samuelsson K, van Dijk CN, Karlsson J, Fu FH. “Anatomic” anterior cruciate ligament reconstruction: a systematic review of surgical techniques and reporting of surgical data. Arthroscopy. 2010;26(9 Suppl):2–12. - PubMed
    1. Yabroudi MA, Irrgang JJ. Rehabilitation and return to play after anatomic anterior cruciate ligament reconstruction. Clin Sports Med. 2013;32(1):165–175. doi: 10.1016/j.csm.2012.08.016. - DOI - PubMed
    1. Kessler MA, Behrend H, Henz S, Stutz G, Rukavina A, Kuster MS. Function, osteoarthritis and activity after ACL-rupture: 11 years follow-up results of conservative versus reconstructive treatment. Knee Surg Sports Traumatol Arthrosc. 2008;16(5):442–448. doi: 10.1007/s00167-008-0498-x. - DOI - PubMed
    1. Oiestad BE, Engebretsen L, Storheim K, Risberg MA. Knee osteoarthritis after anterior cruciate ligament injury: a systematic review. Am J Sports Med. 2009;37(7):1434–1443. doi: 10.1177/0363546509338827. - DOI - PubMed
