Two Cases of Diagnosis and Removal of Endobronchial Hamartoma by Cryotherapy via Flexible Bronchoscopy

Abstract

Although endobronchial hamartoma is a rare benign tumor, most patients with endobronchial hamartoma have respiratory symptoms such as obstructive pneumonia, hemoptysis, cough, or dyspnea due to bronchial obstruction. It can cause irreversible post-obstructive pulmonary destruction, thus early diagnosis and treatment is very important. Recently, there have been cases of neodymium-doped yttrium aluminum garnet (Nd:YAG) laser and electrocautery procedures for bronchoscopic treatment of malignant or benign central airway obstruction with comparable therapeutic efficacy and few complications. Bronchoscopic cryotherapy is a newly developed technique for management of central airway obstruction. Moreover, it provides diagnostic methods with improving diagnostic yield and safety. We report two cases of endobronchial hamartoma, each diagnosed and definitively treated with bronchoscopic techniques. Endobronchial biopsy and removal was successfully performed by cryotherapy via flexible bronchoscopy without notable complications. Follow-up bronchoscopic examinations excluded residual or recurrent disease.

Keywords: Bronchial Neoplasms; Bronchoscopy; Cryotherapy; Hamartoma.

Figure 1

(A-D) Imaging study on admission day suggested obstructive pneumonia on superior segment of right lower lung (RS6). (A, B) Posterior-anterior (PA) view and lateral view of chest X-ray. (C) Transverse section of chest computed tomography (CT). (D) Coronal section of chest CT. (E-H) Imaging study at 3 months after removal of endobronchial hamartoma on superior segmental bronchus of right lower lung (RB6) showed completely resolution of previous obstructive pneumonia on RS6. (E, F) PA view and lateral view of chest X-ray. (G) Transverse section of chest CT. (H) Coronal section of chest CT.

Figure 2

(A, B) The bronchoscopic examination showed the superior segmental bronchus of right lower lung (RB6) was obstructed by pedunculated mass. (A) White light image. (B) Autofluorescence image. (C-G) Procedure image of resection of the mass on RB6 with cryotherapy. Biopsy showed chondroid hamartoma (H&E stain, ×100) (H) and bronchoscopic examination after 3 months after resection of endobronchial hamartoma showed good patency without any obstruction of RB6 (I, J).

Figure 3

(A-C) Imaging study of personal health examination showed a 1.1 cm-sized fat density lesion on superior segmental bronchus of left lower lung (LB6). (A) Posterior-anterior (PA) view of chest X-ray. (B) Transverse section of chest computed tomography (CT). (C) Coronal section of chest CT. (D, E) Imaging study at 1 month after resection of endobronchial hamartoma on LB6. (D) PA view of chest X-ray. (E) Lateral view of chest X-ray.

Figure 4

(A, B) The bronchoscopic examination showed the superior segmental bronchus of left lower lung (LB6) was obstructed by pedunculated mass. (A) White light image. (B) Autofluorescence image. (C-G) Procedure image of resection of the mass on LB6 with cryotherapy. Biopsy showed hamartoma (H&E stain, ×100) (H) and bronchoscopic examination after 1 month after resection of endobronchial hamartoma showed good patency without any obstruction of LB6 (I, J).
