Observational Study
. 2014 Jul 16;4(7):e005308.
doi: 10.1136/bmjopen-2014-005308.

Prevalence of birefringent crystals in cardiac and prostatic tissues, an observational study

Jane J Park  1 , Martine P Roudier  2 , Divya Soman  1 , Nahush A Mokadam  3 , Peter A Simkin  1
Affiliations
Observational Study

Prevalence of birefringent crystals in cardiac and prostatic tissues, an observational study

Jane J Park et al. BMJ Open. .

Abstract

Introduction: The prevalence of urate crystals in residual tissue samples from coronary arteries, aortic valves and prostate glands was assessed.

Methods: Alcohol-fixed coronary arteries from 55 explanted hearts, alcohol-fixed aortic valves collected from 75 valve replacement surgeries and 40 frozen, unfixed prostate specimens resected during cancer surgery were examined for birefringent crystals with polarising microscopy.

Results: In the 55 explanted hearts, 6 (10.9%) contained a coronary artery with birefringent crystals. One of the 75 aortic valves (1.4%) contained negatively and positively birefringent crystals. Nineteen of the 40 (47.5%) prostates contained birefringent crystals.

Conclusions: We found that a remarkable percentage of coronary arteries and prostate specimens contained birefringent crystals. Crystal presence is an obvious prerequisite for possible crystal induced-inflammation in these tissues, just as similar crystals elicit a gouty inflammatory cascade in synovial joints. Further studies are necessary to determine whether urate crystals may play this role in these tissues and, if so, to establish whether urate-lowering therapy may be beneficial in prostatitis and coronary disease.

PubMed Disclaimer

Figures

Figure 1
Figure 1
Intracellular negatively birefringent crystals in the intima of a left anterior descending artery (left) as seen with polarising microscopy. White arrow denotes a first-order red plate axis. Deconvolution confocal microscopy image of the same cell showing intracellular crystals (right).
Figure 2
Figure 2
Microtophus in the intima of a left anterior descending artery.
Figure 3
Figure 3
Microtophi in the adventitia of a right coronary artery.
Figure 4
Figure 4
Positively and negatively birefringent crystals within the prostate gland lumen.
See this image and copyright information in PMC

References

    1. Forbess LJ, Fields TR. The broad spectrum of urate crystal deposition: unusual presentations of gouty tophi. Semin Arthritis Rheum 2012;42:146–54 - PubMed
    1. Weiss TE, Segaloff A. Gouty arthritis and gout: an ancient disease with modern interest. Springfield, IL: Thomas, 1959
    1. Dalbeth N, Kalluru R, Aati O, et al. Tendon involvement in the feet of patients with gout: a dual-energy CT study. Ann Rheum Dis 2013;72:1545–8 - PubMed
    1. Gruber M, Bodner G, Rath E, et al. Dual-energy computed tomography compared with ultrasound in the diagnosis of gout. Rheumatology (Oxford) 2013;72:1545–8 - PubMed
    1. McQueen FM, Reeves Q, Dalbeth N. New insights into an old disease: advanced imaging in the diagnosis and management of gout. Postgrad Med J 2013;89:87–93 - PubMed
