Comparative Study
. 2015 Jan-Feb;56(1):46-54.
doi: 10.1111/vru.12185. Epub 2014 Jul 26.

Effects of two different anesthetic protocols on 64-MDCT coronary angiography in dogs

Randi Drees  1 , Rebecca A Johnson, Marie Pinkerton, Alejandro Munoz Del Rio, Jimmy H Saunders, Christopher J François
Affiliations
Comparative Study

Effects of two different anesthetic protocols on 64-MDCT coronary angiography in dogs

Randi Drees et al. Vet Radiol Ultrasound. 2015 Jan-Feb.

Abstract

Heart rate is a major factor influencing diagnostic image quality in computed tomographic coronary artery angiography (MDCT-CA), with an ideal heart rate of 60-65 beats/min in humans. The purpose of this prospective study was to compare effects of two different clinically applicable anesthetic protocols on cardiovascular parameters and 64-MDCT-CA quality in 10 healthy dogs. Scan protocols and bolus volumes were standardized. Image evaluations were performed in random order by a board-certified veterinary radiologist who was unaware of anesthetic protocols used. Heart rate during image acquisition did not differ between protocols (P = 1), with 80.6 ± 7.5 bpm for protocol A and 79.2 ± 14.2 bpm for protocol B. Mean blood pressure was significantly higher (P > 0.05) using protocol B (protocol A 62.9 ± 9.1 vs. protocol B 72.4 ± 15.9 mmHg). The R-R intervals allowing for best depiction of individual coronary artery segments were found in the end diastolic period and varied between the 70% and 95% interval. Diagnostic quality was rated excellent, good, and moderate in the majority of the segments evaluated, with higher scores given for more proximal segments and lower for more distal segments, respectively. Blur was the most commonly observed artifact and mainly affected the distal segments. No significant differences were identified between the two protocols for optimal reconstruction interval, diagnostic quality and measured length individual segments, or proximal diameter of the coronary arteries (P = 1). Findings indicated that, when used with a standardized bolus volume, both of these anesthetic protocols yielded diagnostic quality coronary 64-MDCT-CA exams in healthy dogs.

Keywords: computed tomography; dexmedetomidine; fentanyl; heart; midazolam.

PubMed Disclaimer

Figures

Figure 1
Figure 1
Evaluation of the individual coronary artery segments: Excellent depiction of the left coronary artery (LCA) and the proximal portion of the left interventricular paraconal branch (LIVP 1, arrows; A). Good depiction of the right coronary artery (RCA 2, arrows; B). Moderate depiction of the right coronary artery, blur of the vessel margins is also present (RCA 2, arrows; C). Poor depiction of the distal segment of the left circumflex coronary artery, blur of the vessel margins is also present (LCX 4, arrows; D). Due to cardiac motion the right coronary artery (RCA 2) is depicted as two vessels (arrows, E). aAO = ascending aorta, dAO = descending aorta.
Figure 1
Figure 1
Evaluation of the individual coronary artery segments: Excellent depiction of the left coronary artery (LCA) and the proximal portion of the left interventricular paraconal branch (LIVP 1, arrows; A). Good depiction of the right coronary artery (RCA 2, arrows; B). Moderate depiction of the right coronary artery, blur of the vessel margins is also present (RCA 2, arrows; C). Poor depiction of the distal segment of the left circumflex coronary artery, blur of the vessel margins is also present (LCX 4, arrows; D). Due to cardiac motion the right coronary artery (RCA 2) is depicted as two vessels (arrows, E). aAO = ascending aorta, dAO = descending aorta.
Figure 1
Figure 1
Evaluation of the individual coronary artery segments: Excellent depiction of the left coronary artery (LCA) and the proximal portion of the left interventricular paraconal branch (LIVP 1, arrows; A). Good depiction of the right coronary artery (RCA 2, arrows; B). Moderate depiction of the right coronary artery, blur of the vessel margins is also present (RCA 2, arrows; C). Poor depiction of the distal segment of the left circumflex coronary artery, blur of the vessel margins is also present (LCX 4, arrows; D). Due to cardiac motion the right coronary artery (RCA 2) is depicted as two vessels (arrows, E). aAO = ascending aorta, dAO = descending aorta.
Figure 1
Figure 1
Evaluation of the individual coronary artery segments: Excellent depiction of the left coronary artery (LCA) and the proximal portion of the left interventricular paraconal branch (LIVP 1, arrows; A). Good depiction of the right coronary artery (RCA 2, arrows; B). Moderate depiction of the right coronary artery, blur of the vessel margins is also present (RCA 2, arrows; C). Poor depiction of the distal segment of the left circumflex coronary artery, blur of the vessel margins is also present (LCX 4, arrows; D). Due to cardiac motion the right coronary artery (RCA 2) is depicted as two vessels (arrows, E). aAO = ascending aorta, dAO = descending aorta.
Figure 1
Figure 1
Evaluation of the individual coronary artery segments: Excellent depiction of the left coronary artery (LCA) and the proximal portion of the left interventricular paraconal branch (LIVP 1, arrows; A). Good depiction of the right coronary artery (RCA 2, arrows; B). Moderate depiction of the right coronary artery, blur of the vessel margins is also present (RCA 2, arrows; C). Poor depiction of the distal segment of the left circumflex coronary artery, blur of the vessel margins is also present (LCX 4, arrows; D). Due to cardiac motion the right coronary artery (RCA 2) is depicted as two vessels (arrows, E). aAO = ascending aorta, dAO = descending aorta.
See this image and copyright information in PMC

References

    1. Buchanan JW. Pulmonic stenosis caused by single coronary artery in dogs: four cases (1965–1984) Journal of the American Veterinary Medical Association. 1990;196:115–120. - PubMed
    1. Buchanan JW. Pathogenesis of single right coronary artery and pulmonic stenosis in English Bulldogs. J Vet Int Med. 2001;15:101–104. - PubMed
    1. Liu S, Tappe JP, Fox PR. Clical and pathological findings in dogs with atheroclerosis: 21 cases. J Am Vet Med Assoc. 1986:227–232. - PubMed
    1. Drees R, Frydrychowicz A, Reeder SB, Pinkerton ME, Johnson R. 64-multidetector computed tomographic angiography of the canine coronary arteries. J Vet Radiol & Ultrasound. 2011;52:507–515. - PMC - PubMed
    1. Menke J, Unterberg-Buchwald C, Staab W, Sohns JM, Seif Amir Hosseini A, Schwarz A. Head-to-head comparison of prospectively triggered vs retrospectively gated coronary computed tomography angiography: Meta-analysis of diagnostic accuracy, image quality, and radiation dose. Am Heart J. 2013;165:154–163. e153. - PubMed
