. 2014 Dec;20(6):686-92.
doi: 10.15274/INR-2014-10064. Epub 2014 Dec 5.

Contrast-Enhanced and Time-of-Flight MR Angiographic Assessment of Endovascular Coiled Intracranial Aneurysms at 1.5 T

Akin Levent  1 , Ihsan Yuce  2 , Suat Eren  3 , Omer Ozyigit  3 , Mecit Kantarci  3
Affiliations

Contrast-Enhanced and Time-of-Flight MR Angiographic Assessment of Endovascular Coiled Intracranial Aneurysms at 1.5 T

Akin Levent et al. Interv Neuroradiol. 2014 Dec.

Abstract

This study evaluated contrast-enhanced magnetic resonance angiography (CE-MRA) and three-dimensional time-of-flight magnetic resonance angiography (3D-TOF-MRA) through comparisons with digital subtraction angiography (DSA) for the follow-up of intracranial aneurysms treated with detachable coils. Sixty-seven patients with 79 aneurysms underwent 3D-TOF-MRA, CE-MRA, and catheter angiography one year after coiling. Two independent observers classified recanalization status on images as neck or body remnant or no recanalization. For 3D-TOF-MRA and CE-MRA, the intermodality agreement, interobserver agreement, and correlation with angiography were assessed. Sixty-seven patients with 79 coiled aneurysms agreed to participate in the study. Three aneurysms could not be detected on 3D-TOF-MRA, so they were excluded from this study. Interobserver agreement was very good for 3D-TOF-MRA and CE-MRA (kappa (κ): 0.87, 0.94, respectively). Correlation of TOF-MRA with angiography was good (κ: 0.76). Correlation of CE-MRA with angiography was excellent (κ: 0.91). The sensitivity and specificity of TOF-MRA were 92% and 98%, respectively. The sensitivity and specificity of CE-MRA were 96% and 98%, respectively. After selective embolization of intracranial aneurysms, CE-MRA is useful and comparable to DSA in the assessment of aneurysmal recanalization. Agreement with the gold standard is stronger with CE-MRA than with 3D-TOF-MRA.

Keywords: CE angiography; TOF angiography; coiled aneurysm follow-up.

PubMed Disclaimer

Figures

Figure 1
Figure 1
DSA image shows an ACoA aneurysm (A) and coiled aneurysm (B) after endovascular treatment (arrowheads). Follow-up 3D-TOF-MRA (C), CE-MRA (D) and DSA (E) images at 12 months show a body remnant (dashed arrows).
Figure 2
Figure 2
Disagreement between 3D-TOF-MRA and DSA on the occlusion of an ACoA aneurysm. Follow-up TOF-MRA (A) and CE-MRA (B) images at 12 months show a small neck remnant (false positive neck remnant). Follow-up DSA image (C) at 12 months shows complete occlusion (arrows).
See this image and copyright information in PMC

Similar articles

See all similar articles

Cited by

See all "Cited by" articles

References

    1. Molyneux A, Kerr R, Stratton I, et al. International Subarachnoid Aneurysm Trial (ISAT) Collaborative Group. International Subarachnoid Aneurysm Trial (ISAT) of neurosurgical clipping versus endovascular coiling in 2143 patients with ruptured intracranial aneurysms: a randomised trial. Lancet. 2002;360(9342):1267–1274. doi: 10.1016/S0140-6736(02)11314-6. - DOI - PubMed
    1. Vrsajkov V, Kolak R, Uram-Benka A, et al. Anesthesia, complications, and clinical outcome for ruptured intracranial aneurysms: a retrospective comparison between endovascular coiling and neurosurgical clipping. Turk J Med Sci. 2012;42(3):477–483.
    1. Hirsch JA, Bendok BR, Paulsen RD, et al. Midterm clinical experience with a complex-shaped detachable platinum coil system for the treatment of cerebral aneurysms: Trufill DCS Orbit detachable coil system registry interim results. J Vasc Interv Radiol. 2007;18(12):1487–1494. doi: 10.1016/j.jvir.2007.07.020. - DOI - PubMed
    1. Molyneux AJ, Kerr RS, Yu LM, et al. International Subarachnoid Aneurysm Trial (ISAT) Collaborative Group. International subarachnoid aneurysm trial (ISAT) of neurosurgical clipping versus endovascular coiling in 2143 patients with ruptured intracranial aneurysms: a randomised comparison of effects on survival, dependency, seizures, rebleeding, subgroups and aneurysm occlusion. Lancet. 2005;366(9488):809–817. doi: 10.1016/S0140-6736(05)67214-5. - DOI - PubMed
    1. Shankar JJ, Lum C, Parikh N, et al. Long-term prospective follow-up of intracranial aneurysms treated with endovascular coiling using contrast-enhanced MR angiography. Am J Neuroradiol. 2010;31(7):1211–1215. doi: 10.3174/ajnr.A2064. - DOI - PMC - PubMed
