. 2015 Feb 28;50(2):164-7.
doi: 10.1016/j.rboe.2015.02.010. eCollection 2015 Mar-Apr.

Anatomical reference point for harvesting a flexor graft during arthroscopic reconstruction of the anterior cruciate ligament

Clécio de Lima Lopes  1 , Gabriel Arantes  1 , Rodrigo Victor Lapenda de Oliveira  1 , Dilamar Moreira Pinto  1 , Marcelo Carvalho Krause Gonçalves  1 , Romeu Carvalho Krause Gonçalves  1
Affiliations

Anatomical reference point for harvesting a flexor graft during arthroscopic reconstruction of the anterior cruciate ligament

Clécio de Lima Lopes et al. Rev Bras Ortop. .

Abstract
in English, Portuguese

Objectives: To evaluate the prevalence of a vascular network adjacent to the insertion of the pes anserinus, so that it could be used as an anatomical reference point to facilitate harvesting flexor grafts for arthroscopic reconstruction of the anterior cruciate ligament (ACL).

Methods: Thirty patients with ACL tears who were going to undergo ACL reconstruction using the tendons of the semitendinosus and gracilis muscles as grafts were selected randomly. During the harvesting of these tendons, the presence or absence of this anatomical reference point was noted.

Results: All the patients presented a vascular network of greater or lesser diameter.

Conclusion: The vascular network seems to be a good reference point during harvesting of the tendons of the semitendinosus and gracilis muscles, for facilitating graft harvesting.

Objetivos: Avaliar a prevalência da trama vascular adjacente à inserção da pata de ganso, para que possa ser usada como referência anatômica para facilitar a retirada de enxerto dos flexores na reconstrução artroscópica do ligamento cruzado anterior (LCA).

Métodos: Foram selecionados de forma aleatória 30 pacientes com rotura do LCA, os quais foram submetidos à reconstrução do LCA tendo como enxerto os tendões do semitendíneo (ST) e grácil (G). Durante a retirada dos tendões do ST e G, foi observada a presença ou ausência da referência anatômica.

Resultados: Todos os pacientes apresentaram trama vascular em menor ou maior diâmetro.

Conclusão: O uso da trama vascular durante retirada dos tendões do ST e G parece ser uma boa referência anatômica para facilitar a retirada do enxerto.

Keywords: Anterior cruciate ligament; Tendons/anatomy and histology; Tendons/transplantation.

PubMed Disclaimer

Figures

Fig. 1
Fig. 1
Anatomical specimen from the knee of a fresh cadaver in which the femoral artery was catheterized and received administration of a gelatinous solution of India ink, which showed the vascular arch that surrounds the insertion of the pes anserinus. Arrows show the tributaries of the vascular arch: (1) medial inferior genicular artery (superficial and deep branches); (2) lateral inferior genicular artery; (3) anterior tibial recurrent artery.
Fig. 2
Fig. 2
Presence of the vascular arch adjacent to the insertion of the pes anserinus.
Fig. 3
Fig. 3
Incision in the pes anserinus, which follows the path of the vascular arch.
Fig. 4
Fig. 4
Pes anserinus totally detached from its insertion.
Fig. 5
Fig. 5
Identification of the semitendinosus and gracilis tendons.
See this image and copyright information in PMC

References

    1. Charalambous C.P., Kwaees T.A. Anatomical considerations in hamstring tendon harvesting for anterior cruciate ligament reconstruction. Muscles Ligaments Tendons J. 2013;2(4):253–257. - PMC - PubMed
    1. Wilson T.J., Lubowitz J.H. Minimally invasive posterior hamstring harvest. Arthrosc Tech. 2013;2(3):e299–e301. - PMC - PubMed
    1. Mochizuki T., Akita K., Munetan T., Sato T. Pesanserinus: layered supportive structure on the medial side of the knee. Clin Anat. 2004;17(1):50–54. - PubMed
    1. Pagnani M.J., Warner J.J., O’Brien S.J., Warren R.F. Anatomic considerations in harvesting the semitendinosus and gracilis tendons and a technique of harvest. Am J Sports Med. 1993;21(4):565–571. - PubMed
    1. Zaffagnini S., Golanò P., Farinas O., Depasquale V., Strocchi R., Cortecchia S. Vascularity and neuroreceptors of the pesanserinus: anatomic study. Clin Anat. 2003;16(1):19–24. - PubMed
