A Review of the Literature on Extrarenal Retroperitoneal Angiomyolipoma

Abstract

Background: Extrarenal retroperitoneal angiomyolipomas are rare.

Aim: To review the literature.

Results: Angiomyolipomas, previously classified as hamartomas, are now classified as benign tumours. Thirty cases of primary retroperitoneal angiomyolipomas have been reported. Diagnosis of the disease upon is based radiological and pathological findings of triphasic features of (a) fat and (b) blood vessels and myoid tissue. Immunohistochemistry tends to be positive for HMB45, MART1, HHF35, calponin, NKI-C3, and CD117. The lesion is common in women. Treatment options have included the following: (a) radical surgical excision of the lesion with renal sparing surgery or radical nephrectomy in cases where malignant tumours could not be excluded and (b) selective embolization of the lesion alone or prior to surgical excision. One case of retroperitoneal angiomyolipoma was reported in a patient 15 years after undergoing radical nephrectomy for angiomyolipoma of kidney and two cases of distant metastases of angiomyolipoma have been reported following radical resection of the tumour.

Conclusions: With the report of two cases of metastases ensuing surgical resection of the primary lesions there is need for academic pathologists to debate and review angiomyolipomas to decide whether to reclassify angiomyolipomas as slow-growing malignant tumours or whether the reported cases of metastases were de novo tumours or metastatic lesions.

Figure 1

(a) Oral contrast and (b) IV and oral contrast: abdominal computerized tomography demonstrating an encapsulated fatty vascular mass (white arrows) lateral to the left kidney measuring 19.3 cm × 13.5 cm × 10.7 cm with prominent vascular dependence on the left renal vein and artery as well as a 2 cm posterior midpole homogeneous fatty density (yellow arrow). Left colon is laterally displaced (orange arrow). Reproduced from [18].

Figure 2

Abdominal magnetic resonance imaging demonstrating a large fatty encapsulated mass (white asterisk) measuring 19.3 cm × 13.5 cm × 10.7 cm with prominent vascularity (white arrows). The anatomic relationship between the mass and the left kidney can be well seen in Figure 2(b). Reproduced from [18].

Figure 3

Gross image of the en bloc resected mass including the left kidney (black arrow), demonstrating a well-encapsulated fatty mass attached to the upper pole of the kidney (white arrow), with a smooth outer surface measuring 23 cm × 14 cm × 9 cm. Reproduced from [18].

Figure 4

Extrarenal mass (haematoxylin and eosin). Photomicrograph of the mass demonstrate mature adipose tissue with a tortuous thick blood vessel (black arrow) ((a); ×20) and bundles of smooth muscles lacking elastic tissue lamina ((b); ×40), adipose tissue with small areas of smooth muscle with epithelioid features ((c); ×40). Focal staining with HMB45 antibody was positive (blue star) ((d); ×40), consistent with angiomyolipoma. Reproduced from [18].
