Case Reports
. 2016 Apr 19;2016(4):rjw044.
doi: 10.1093/jscr/rjw044.

Superior vena cava syndrome from an invasive thymoma with transcaval invasion to the right atrium

Ashwad Afzal  1 , Ivan Wong  1 , Aleksandr Korniyenko  2 , Alex Ivanov  2 , Berhane Worku  3 , Iosif Gulkarov  4
Affiliations
Case Reports

Superior vena cava syndrome from an invasive thymoma with transcaval invasion to the right atrium

Ashwad Afzal et al. J Surg Case Rep. .

Abstract

Invasive thymoma with transcaval extension to the right atrium is a rare cause of superior vena cava syndrome. We present a case on a 74-year-old female presenting with dyspnea on exertion, and facial and upper extremity swelling. Physical examination revealed mild facial swelling, non-pitting edema involving the upper extremities and distention of superficial veins of the anterior chest wall and jugular veins. An echocardiogram showed moderate right atrial dilation with a mobile mass in the atrial cavity prolapsing through the tricuspid valve. Cardiac magnetic resonance imaging revealed a 9.9 × 4.3 cm heterogeneous mass in the anterior mediastinum compressing the superior vena cava and endovenously extending into the right atrium. Tissue biopsy of the mediastinal mass revealed a type B1 thymoma, further staged as a Masaoka IVa invasive thymoma that underwent successfulen blocresection followed by removal of intracaval and right atrial mass.

PubMed Disclaimer

Figures

Figure 1:
Figure 1:
CMR sagittal view: large anterior mediastinal mass with extension into the right atrium.
Figure 2:
Figure 2:
CMR coronal view: anterior mediastinal mass invading superior vena cava and extending into the right atrium.
Figure 3:
Figure 3:
CMR axial four-chamber view: mass in the right atrial cavity protruding through the tricuspid valve into the right ventricle.
See this image and copyright information in PMC

Similar articles

See all similar articles

Cited by

References

    1. Kurata A, Saji H, Ikeda N, Kuroda M. Intracaval and intracardiac extension of invasive thymoma complicated by superior and inferior vena cava syndrome. Pathol Int 2013;63:56–62. - PubMed
    1. Dib HR, Friedman B, Khouli HI, Gerber DR, Weiss RL. Malignant thymoma. A complicated triad of SVC syndrome, cardiac tamponade, and DIC. Chest 1994;105:941. - PubMed
    1. Dursun M, Sarvar S, Cekrezi B, Kaba E, Bakir B, Toker A. Cardiac metastasis from invasive thymoma via the superior vena cava: cardiac MRI findings. Cardiovasc Intervent Radiol 2008;31(Suppl 2):S209–12. - PubMed
    1. Kim DJ, Yang WI, Choi SS, Kim KD, Chung KY. Prognostic and clinical relevance of the World Health Organization schema for the classification of thymic epithelial tumors: a clinicopathologic study of 108 patients and literature review. Chest 2005;127:755. - PubMed
    1. Rena O, Papalia E, Maggi G, Oliaro A, Ruffini E, Filosso P et al. . World Health Organization histologic classification: an independent prognostic factor in resected thymomas. Lung Cancer 2005;50:59. - PubMed
