Case Reports
. 2017 Sep 8;11(1):255.
doi: 10.1186/s13256-017-1417-x.

Differential lung ventilation via tracheostomy using two endotracheal tubes in an infant: a case report

Demet Demirkol  1 , Yasemin Ataman  2 , Gökhan Gündoğdu  3
Affiliations
Case Reports

Differential lung ventilation via tracheostomy using two endotracheal tubes in an infant: a case report

Demet Demirkol et al. J Med Case Rep. .

Abstract

Background: This case report presents differential lung ventilation in an infant. The aim is to define an alternative technique for performing differential lung ventilation in children. To the best of our knowledge, this is the first report of this kind.

Case presentation: A 4.2-kg, 2.5-month-old Asian boy was referred to our facility with refractory hypoxemia and hypercarbia due to asymmetric lung disease with atelectasis of the left lung and hyperinflation of the right lung. He was unresponsive to conventional ventilator strategies; different ventilator settings were required. To perform differential lung ventilation, two separate single-lumen endotracheal tubes were inserted into the main bronchus of each lung by tracheotomy; the tracheal tubes were attached to discrete ventilators. The left lung was ventilated with a lung salvage strategy using high-frequency oscillatory ventilation, and the right lung was ventilated with a lung-protective strategy using pressure-regulated volume control mode. Differential lung ventilation was performed successfully with this technique without complications.

Conclusions: Differential lung ventilation may be a lifesaving procedure in select patients who have asymmetric lung disease. Inserting two single-lumen endotracheal tubes via tracheotomy for differential lung ventilation can be an effective and safe alternative method.

Keywords: Asymmetric lung disease; Differential lung ventilation; Infant; Single-lumen tubes; Tracheotomy.

PubMed Disclaimer

Conflict of interest statement

Consent for publication

Written informed consent was obtained from the patient’s legal guardians for publication of this case report and any accompanying images. A copy of the written consent is available for review by the Editor-in-Chief of this journal.

Competing interests

The authors declare that they have no competing interests.

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Figures

Fig. 1
Fig. 1
Chest radiographic image showing asymmetric lung injury with severe left-lung atelectasis and right-lung hyperinflation on the 14th day of hospitalization
Fig. 2
Fig. 2
Chest radiographic image revealing that the atelectasis of the left lung and hyperinflation of the right lung were ameliorated after 12 hours of differential lung ventilation
See this image and copyright information in PMC

Similar articles

See all similar articles

Cited by

References

    1. Hirata N, Sato H, Toyoshima Y, Kawana S, Namiki A. Differential lung ventilation by use of a combination of a laryngeal mask airway and an endotracheal tube in a pediatric patient with atelectasis of the right lung. Masui. 2003;52:906–8. - PubMed
    1. Arai T, Yamashita M. Differential lung ventilation in an infant using LMA and a long tracheal tube. Paediatr Anaesth. 2003;13:438–40. doi: 10.1046/j.1460-9592.2003.01060.x. - DOI - PubMed
    1. Garlick J, Maxson T, Imamura M, Green J, Prodhan P. Differential lung ventilation and venovenous extracorporeal oxygenation for traumatic bronchopleural fistula. Ann Thorac Surg. 2013;96:1859–60. doi: 10.1016/j.athoracsur.2013.01.094. - DOI - PubMed
    1. Achar S, Chaudhuri S, Krishna HM, Sagar MS. Re-expansion pulmonary oedema- differential lung ventilation comes to rescue. Indian J Anaesth. 2014;58:330–3. doi: 10.4103/0019-5049.135051. - DOI - PMC - PubMed
    1. Cinnella G, Dambrosio CG, Brienza N, Giuliani R, Bruno F, Flore T, Brienza A. Independent lung ventilation in patients with unilateral pulmonary contusion. Intensive Care Med. 2001;27:1860–7. doi: 10.1007/s00134-001-1149-6. - DOI - PubMed
