. 2018 Feb 1;36(1):76-81.
doi: 10.7518/hxkq.2018.01.015.

[Experimental research on Arginine-gingipain A gene vaccine from Porphyromonas gingivalis that prevents peri-implantitis in Beagle dogs]

[Article in Chinese]
Li Chuanhua  1 , Wang Zhifeng  2 , Zhu Lina  2 , Fan Xin  3 , Lan Jing  1
Affiliations

[Experimental research on Arginine-gingipain A gene vaccine from Porphyromonas gingivalis that prevents peri-implantitis in Beagle dogs]

[Article in Chinese]
Li Chuanhua et al. Hua Xi Kou Qiang Yi Xue Za Zhi. .

Abstract
in English, Chinese

Objective: This study aims to use Arginine-gingipain A gene vaccine (pVAX1-rgpA) to immunize adult Beagle dogs and to evaluate its effect during peri-implantitis progression and development.

Methods: Plasmid pVAX1-rgpA was constructed. The second and third bilateral mandible premolars of 15 adult Beagle dogs were extracted, and the implants were placed immediately. After 3 months, the animals were randomly divided into groups A, B, and C. Afterward, the animals were immunized thrice with plasmid pVAX1-rgpA, with heat-killed Porphyromonas gingivalis, or pVAX1, respectively. IgG in the serum and secretory IgA (sIgA) in saliva were quantitatively analyzed by enzyme-linked immunosorbent assay before and after 2 weeks of immunization. Peri-implantitis was induced with cotton ligatures fixed around the neck of implants. Probing depth (PD) and bleeding on probing were recorded. All animals were sacrificed after ligaturation for 6 weeks. Decalcified sections with thickness of 50 μm were prepared and dyed with methylene blue to observe the bone phenotype around implants.

Results: Levels of serum IgG and sIgA in saliva were higher in groups A and B after immunization than before the process (P<0.05) and higher than those in group C (P<0.05). However, no difference was observed between groups A and B (P>0.05). At 4 and 6 weeks after ligaturation, PD of the ligatured side in group C was higher than that in groups A and B (P<0.05). On the other hand, no difference was identified between groups A and B (P>0.05). Bone loss in group A was significantly lower than that of the other groups (P<0.05). Abundant inflammatory cells and bacteria were present in the bone loss area around the implants in the three groups, as identified through hard tissue section observation. However, group C presented the most number of inflammatory cells and bacteria in the bone loss area around the implants.

Conclusions: IgG and sIgA can be generated by immunity with rgpA DNA vaccine, which can significantly slow down bone loss during experimental peri-implantitis in dogs.

目的 构建牙龈卟啉单胞菌精氨酸特异性牙龈素基因疫苗pVAX1-rgpA，并对成年犬进行免疫接种，观察该疫苗在防治种植体周围炎发生发展中的作用。方法 构建真核表达质粒pVAX1-rgpA。拔除15只成年犬下颌双侧第二、三前磨牙，随机即刻植入种植体。3个月后，实验犬随机均分成A、B、C组，分别接种重组质粒pVAX1-rgpA、热失活牙龈卟啉单胞菌、空白质粒pVAX1，连续接种3次。接种开始前、接种结束2周后采用酶联免疫吸附试验检测血清IgG和唾液分泌型IgA（sIgA）含量。随机选取一侧采用丝线结扎法构建种植体周围炎，并检测种植体周探诊深度（PD）和探诊出血指数（BOP）。结扎6周后处死所有动物，制作50 μm厚的硬组织切片，亚甲基蓝染色后观察种植体周骨丧失程度。结果 A、B组动物免疫后，IgG、sIgA抗体较未免疫前明显增高（P<0.05），同时较C组升高（P<0.05），但A、B组间差异无统计学意义（P>0.05）。丝线结扎第4和6周时，C组结扎侧的PD明显高于A、B组（P<0.05），A、B组间差异无明显统计学意义（P>0.05）。A组结扎侧骨丧失量明显小于其他两组（P<0.05）。硬组织切片可见，各组种植体周骨丧失区均有大量的炎症细胞和细菌存在，C组结扎侧最严重。结论 精氨酸特异性牙龈素（rgpA）基因疫苗产生的IgG和sIgA，能有效减弱犬种植体周围炎的骨丧失量。.

Keywords: Arginine-gingipains; Porphyromonas gingivalis; dental implant; gene vaccine; peri-implantitis.

PubMed Disclaimer

Figures

图 1
图 1. 垂直向骨丧失示意图
Fig 1 Schematic diagram of vertical bone loss a：种植体颈部有涂层处开始至骨丧失区最底端的距离。
图 2
图 2. 种植体植入3个月时的临床观察及X线检查
Fig 2 Clinical observation and the radiographs of implants and alveolar bone after three months A：种植体周牙龈呈深红色，质韧而有弹性，无炎症表现；B：X线检测见种植体与骨间结合良好，无明显骨丧失。
图 3
图 3. 丝线结扎后6周时，3组动物的临床观察（上）及X线检查（下）情况
Fig 3 Clinical observation (the top graphs) and the radiographs (the bottom graphs) of three groups after six weeks A：A1组种植体周软组织炎症明显；B：B1组炎症较A1组更加明显，红肿出血；C：C1组一些种植体螺纹暴露在口腔中，炎症较其他两组更重；D：A1组种植体周见小面积透射区域；E：B1组种植体周见明显弹坑状透射区域；F：C1组种植体颈部透射面积较其他两组更大。
图 4
图 4. A1、B1、C1组的硬组织切片观察
Fig 4 The histological images of A1, B1, C1 groups 左：A1组的骨丧失量最小；中：B1组种植体周围可见明显的颊舌侧骨丧失；右：C1组可见明显的垂直向和水平向的骨丧失，种植体周有大量炎症细胞存在。
See this image and copyright information in PMC

Similar articles

See all similar articles

References

    1. Corbella S, Del Fabbro M, Taschieri S, et al. Clinical evaluation of an implant maintenance protocol for the prevention of peri-implant diseases in patients treated with immediately loaded full-arch rehabilitations[J] Int J Dent Hyg. 2011;9(3):216–222. - PubMed
    1. Paramonov N, Rangarajan M, Hashim A, et al. Structural analysis of a novel anionic polysaccharide from Porphyromonas gingivalis strain W50 related to Arg-gingipainglycans[J] Mol Microbiol. 2005;58(3):847–863. - PubMed
    1. Yamatake K, Maeda M, Kadowaki T, et al. Role for gingipains in Porphyromonas gingivalis traffic to phagolysosomes and survival in human aortic endothelial cells[J] Infect Immun. 2007;5(5):2090–2100. - PMC - PubMed
    1. Genco CA, Kapczynski DR, Cutler CW, et al. Influence of immunization on Porphyromonas gingivalis colonization and invasion in the mouse chamber model[J] Infect Immun. 1992;60(4):1447–1454. - PMC - PubMed
    1. Ebersole JL, Brunsvold M, Steffensen B, et al. Effects of immunization with Porphyromonas gingivalis and Prevotella intermedia on progression of ligature-induced periodontitis in the nonhuman primate Macaca fascicularis[J] Infect Immun. 1991;59(10):3351–3359. - PMC - PubMed
