. 2017 Apr 17;32(4):339-346.
doi: 10.5606/ArchRheumatol.2017.5940. eCollection 2017 Dec.

Computer-assisted Joint Space Area Measurement: A New Technique in Patients With Knee Osteoarthritis

İlker Ilhanli  1 , Necip Güder  2 , Alptekin Tosun  3 , Esin Avci  4 , Canan Çelik  1
Affiliations

Computer-assisted Joint Space Area Measurement: A New Technique in Patients With Knee Osteoarthritis

İlker Ilhanli et al. Arch Rheumatol. .

Abstract

Objectives: This study aims to assess the validity and reproducibility of computer-assisted joint space area measurement in knee roentgenograms of patients with knee osteoarthritis and compare it with a qualitative method in knee roentgenograms and quantitative and semi-quantitative methods in magnetic resonance imaging.

Patients and methods: The study included 40 knees of 40 patients diagnosed as osteoarthritis (14 males, 26 females; mean age 57.4±5.9 years; range 47 to 67 years). Only the patients who wrote consents for publication of their radiologic data, and with knee roentgenograms and magnetic resonance images of the same knees were selected. Computer-assisted measurements were applied to joint spaces by two blinded physicians, for two times with an interval of one week. Data were evaluated for intraobserver and interobserver consistency. Also, data were compared with qualitative (Kellgren-Lawrence classification), quantitative (joint space width, cartilage thickness, meniscal thickness in magnetic resonance images) and semi-quantitative methods (whole-organ magnetic resonance imaging score).

Results: Intraobserver consistency was evaluated for each physician, which revealed no differences. Interobserver consistency was evaluated by comparing the measurements of two blinded physicians and no differences were found (p>0.05). There was no significant correlation between the grade of Kellgren-Lawrence classification and other variables; such as grade of meniscus, meniscal thickness, cartilage thickness and computer- assisted joint space area measurements (p>0.05). While there was a positive correlation between computer-assisted joint space area measurement and other quantitative measurements, there was a negative correlation between computer-assisted joint space area measurement and whole-organ magnetic resonance imaging scores.

Conclusion: When compared with qualitative, quantitative, and semi-quantitative methods, computer-assisted joint space area measurement seems to be a useful, reproducible, and cost-effective quantitative method for evaluating knee osteoarthritis.

Keywords: Knee; magnetic resonance imaging; osteoarthritis; roentgenogram.

PubMed Disclaimer

Conflict of interest statement

Conflict of Interest: The authors declared no conflicts of interest with respect to the authorship and/or publication of this article.

Figures

Figure 1
Figure 1. Computer-assisted joint space area measurement of medial and lateral compartments of knee joint.
See this image and copyright information in PMC

Similar articles

See all similar articles

Cited by

References

    1. Peat G, Thomas E, Duncan R, Wood L, Hay E, Croft P. Clinical classification criteria for knee osteoarthritis: performance in the general population and primary care. Ann Rheum Dis. 2006;65:1363–1367. - PMC - PubMed
    1. Kellgren JH, Lawrence JS. Radiological assessment of osteo-arthrosis. Ann Rheum Dis. 1957;16:494–502. - PMC - PubMed
    1. Peterfy CG, Guermazi A, Zaim S, Tirman PF, Miaux Y, White D, et al. Whole-Organ Magnetic Resonance Imaging Score (WORMS) of the knee in osteoarthritis. Osteoarthritis Cartilage. 2004;12:177–190. - PubMed
    1. Peterfy CG, van Dijke CF, Janzen DL, Glüer CC, Namba R, Majumdar S, et al. Quantification of articular cartilage in the knee with pulsed saturation transfer subtraction and fat-suppressed MR imaging: optimization and validation. Radiology. 1994;192:485–491. - PubMed
    1. Pilch L, Stewart C, Gordon D, Inman R, Parsons K, Pataki I, et al. Assessment of cartilage volume in the femorotibial joint with magnetic resonance imaging and 3D computer reconstruction. J Rheumatol. 1994;21:2307–2321. - PubMed
