. 2018 Dec 8;8(12):1025.
doi: 10.3390/nano8121025.

Hydrothermal Synthesis of CeO₂-SnO₂ Nanoflowers for Improving Triethylamine Gas Sensing Property

Dongping Xue  1   2 , Yan Wang  3 , Jianliang Cao  4 , Zhanying Zhang  5   6
Affiliations

Hydrothermal Synthesis of CeO₂-SnO₂ Nanoflowers for Improving Triethylamine Gas Sensing Property

Dongping Xue et al. Nanomaterials (Basel). .

Abstract

Developing the triethylamine sensor with excellent sensitivity and selectivity is important for detecting the triethylamine concentration change in the environment. In this work, flower-like CeO₂-SnO₂ composites with different contents of CeO₂ were successfully synthesized by the one-step hydrothermal reaction. Some characterization methods were used to research the morphology and structure of the samples. Gas-sensing performance of the CeO₂-SnO₂ gas sensor was also studied and the results show that the flower-like CeO₂-SnO₂ composite showed an enhanced gas-sensing property to triethylamine compared to that of pure SnO₂. The response value of the 5 wt.% CeO₂ content composite based sensor to 200 ppm triethylamine under the optimum working temperature (310 °C) is approximately 3.8 times higher than pure SnO₂. In addition, CeO₂-SnO₂ composite is also significantly more selective for triethylamine than pure SnO₂ and has better linearity over a wide range of triethylamine concentrations. The improved gas-sensing mechanism of the composites toward triethylamine was also carefully discussed.

Keywords: CeO2-SnO2; gas sensor; hydrothermal; nanostructure; triethylamine.

PubMed Disclaimer

Conflict of interest statement

The authors declare no conflict of interest.

Figures

Figure 1
Figure 1
XRD patterns of the samples.
Figure 2
Figure 2
Field-emission scanning electron microscopy (FESEM) images of pure SnO2 (a,b) and SC-5 nanocomposite (c,d) and the EDS images (e-h) of the SC-5 sample.
Figure 3
Figure 3
UV–vis absorption spectra of the synthesized SC-0 and SC-5 samples. The upper right corner inset is the relationship lines of (αhv)2 and hv.
Figure 4
Figure 4
The response of the synthesized samples to 200 ppm TEA at different operating temperatures.
Figure 5
Figure 5
(a) Response of the sensors to different TEA concentrations at 310 °C (the inset shows the response curve in the range of 20–200 ppm), (b) dynamic response-recover curves of the sensors to different TEA concentrations at 310 °C, (c) responses of the SC-0 and SC-5 sensors to five gases of 200 ppm, (d) long-term stability measurements of the SC-5 sensor to 200 ppm TEA at 310 °C.
Figure 6
Figure 6
TEA sensing mechanisms diagram of (a) pure SnO2 and (b) CeO2/SnO2 nanostructure.
Figure 7
Figure 7
Structure diagram of gas sensor.
See this image and copyright information in PMC

References

    1. Xu H.Y., Ju D.X., Li W.R., Zhang J., Wang J.Q., Cao B.Q. Superior triethylamine sensing properties based on TiO2/SnO2 n-n heterojunction nanosheets directly grown on ceramic tubes. Sens. Actuators B Chem. 2016;228:634–642. doi: 10.1016/j.snb.2016.01.059. - DOI
    1. Wu Y., Zhou W., Dong W., Zhao J., Qiao X.Q., Hou D.F., Li D.S., Zhang Q., Feng P.Y. Temperature-Controlled Synthesis of Porous CuO Particles with Different Morphologies for Highly Sensitive Detection of Triethylamine. Cryst. Growth Des. 2017;17:2158–2165. doi: 10.1021/acs.cgd.7b00102. - DOI
    1. Ju D., Xu H., Xu Q., Gong H., Qiu Z., Guo J., Zhang J., Cao B. High triethylamine-sensing properties of NiO/SnO2 hollow sphere P-N heterojunction sensors. Sens. Actuators B Chem. 2015;215:39–44. doi: 10.1016/j.snb.2015.03.015. - DOI
    1. Liu B., Zhang L., Zhao H., Chen Y., Yang H. Synthesis and sensing properties of spherical flowerlike architectures assembled with SnO2 submicron rods. Sens. Actuators B Chem. 2012;173:643–651. doi: 10.1016/j.snb.2012.07.084. - DOI
    1. Cai T., Chen L., Ren Q., Cai S., Zhang J. The biodegradation pathway of triethylamine and its biodegradation by immobilized arthrobacter protophormiae cells. J. Hazard. Mater. 2011;186:59–66. doi: 10.1016/j.jhazmat.2010.10.007. - DOI - PubMed
