An immunosuppressive macrophage profile attenuates the prognostic impact of CD20-positive B cells in human soft tissue sarcoma

Abstract

Background: Immune cells can regulate disease progression and response to treatment in multiple tumor types, but their activities in human soft tissue sarcoma are poorly characterized.

Methods: Marker-defined immune cell subsets were characterized from a tumor microenvironmental perspective in two independent cohorts of human soft tissue sarcoma by multiplex IHC, quantitative PCR and/or bioinformatics.

Results: B cell profiling revealed a prognostic role for CD20 protein (cohort 1, 33 patients) and MS4A1 gene expression (cohort 2, 265 patients). Multiplex IHC and gene correlation analysis supported a role in antigen presentation, immune cell differentiation and T cell activation. The prognostic role of MS4A1 expressing B cells was only observed in an IL10^low, PTGS2^low or CD163^low tumor microenvironment according to the transcriptomic data. IL10 levels consistently correlated with the M2-like macrophage marker CD163, which also defined the majority of macrophages. A polarization of these cells toward a pro-tumoral phenotype was further supported by lack of correlation between CD163 and M1 markers like NOS2, as well as by low abundance of CD80 positive cells in tissue.

Conclusions: Analysis of CD20/MS4A1 expression in soft tissue sarcoma merits further attention as a promising candidate prognostic tool for survival, but not in patients with a pronounced immunosuppressive tumor microenvironment. Macrophages are ubiquitous and polarized toward a protumoral phenotype. This provides a rationale for further studies on B cell function and immunotherapy targeting M2-polarized macrophages.

Keywords: CD20; IL10; M2 macrophages; MS4A1; Prognostic marker; Sarcoma.

Fig. 1

Tumor-associated macrophages outnumber lymphocyte subsets in STS. a Multiplex IHC using the pan-macrophage marker CD68 (blue, left), the B cell marker CD20 (brown, left), the M1-like associated marker CD80 (blue, right) and the M2-associated marker CD163 (red, right). b Immunostaining for CD8 (brown, left) and FOXP3 (brown, right). c Immunostaining for B cells using antibodies targeting CD20, PAX5 and CD19 (brown, Htx as counterstain, tonsil as positive control)

Fig. 2

CD20/MS4A1 expression is prognostic, but only in IL10^low and PTGS2^low tumors. a Kaplan–Meier analysis illustrating the association between CD20 B cell-positive tumors and improved metastasis-free survival (left) and overall survival (right) in the Karolinska STS cohort. b Kaplan–Meier analysis illustrating the association between MS4A1 expression and improved overall survival in the SARC STS cohort. c Kaplan–Meier analysis of CD19 expression and overall survival in the SARC STS cohort (right). d Kaplan–Meier analyses illustrating the prognostic impact of MS4A1 expression in IL10^low tumors (top left), IL10^high tumors (top right), PTGS2^low tumors (bottom left) and PTGS2^high tumors (bottom right) in the SARC STS cohort
