Case Reports
. 2021 May;44(3):425-428.
doi: 10.1080/10790268.2019.1585706. Epub 2019 Mar 18.

Thoracoscopic intercostal to phrenic nerve transfer for diaphragmatic reanimation in a child with tetraplegia

Jacob Latreille  1 , Erika B Lindholm  2 , Dan A Zlotolow  3 , Harsh Grewal  2   3
Affiliations
Case Reports

Thoracoscopic intercostal to phrenic nerve transfer for diaphragmatic reanimation in a child with tetraplegia

Jacob Latreille et al. J Spinal Cord Med. 2021 May.

Abstract

Context: To describe for the first time a novel technique of thoracoscopic intercostal nerve mobilization and intercostal to phrenic nerve transfer in the setting of tetraplegia with the goal of reanimating the diaphragm and decreasing ventilator dependence.Findings: A 5-year-old female on 24 h ventilator support secondary to traumatic tetraplegia was evaluated for possible phrenic nerve pacing. Left-sided phrenic nerve stimulation did not result in diaphragmatic contraction indicating a lower motor neuron injury. The patient underwent thoracoscopic mobilization of the left phrenic nerve and 10th intercostal nerve while positioned in the left lateral decubitus position using four 5 mm trocars. The mobilized intercostal nerve was transected close to its distal anterior termination and coapted without tension to the cut end of the terminal phrenic nerve using fibrin sealant. Lastly, phrenic nerve pacer leads and battery were implanted in the chest wall and connected to the electrode placed on the intercostal nerve. One year following the procedure, the patient was tolerating phrenic pacing during the day while requiring ventilation overnight. Currently, the patient is 2 years post-operative from this procedure and does not require ventilator support.Conclusion/clinical relevance: We have shown for the first time a novel approach of thoracoscopic nerve mobilization and phrenic to intercostal nerve transposition to be both safe and effective for restoring innervation of the diaphragm in a child. This minimally invasive procedure is recommended as the preferred approach to reanimate the diaphragm.

Keywords: Diaphragmatic reanimation; Nerve pacing; Phrenic nerve transfer; Traumatic tetraplegia.

PubMed Disclaimer

Figures

Figure 1.
Figure 1.
Thoracoscopic mobilization of (A) the 10th intercostal nerve (arrow) off of the chest wall, and (B) the phrenic nerve (asterisk) off of the pericardium.
Figure 2.
Figure 2.
(A) The intercostal nerve (arrow) transferred to the left phrenic nerve (asterisk) without tension and (B) coaptation was secured with TISSEEL fibrin.
See this image and copyright information in PMC

Similar articles

See all similar articles

Cited by

References

    1. Kaufman M, Elkwood A, Aboharb F, et al. Diaphragmatic reinnervation in ventilator-dependent patients with cervical spinal cord injury and concomitant phrenic nerve lesions using simultaneous nerve transfers and implantable neurostimulators. J Reconstr Microsurg. 2015;31:391–5. doi: 10.1055/s-0035-1549159 - DOI - PubMed
    1. Krieger L. M., Krieger A. J.. The intercostal to phrenic nerve transfer: an effective means of reanimating the diaphragm in patients with high cervical spine injury. Plast Reconstr Surg. 2000 Apr; 105(4): 1255–61. - PubMed
    1. Huttmann SE, Magnet ES, Karagiannidis C, et al. Quality of life and life satisfaction are severely impaired in patients with long-term invasive ventilation following ICU treatment and unsuccessful weaning. Ann Intens Care. 2018 March; 8(1): 36. doi: 10.1186/s13613-018-0384-8 - DOI - PMC - PubMed
    1. DiMarco AF, Takaoka Y, Kowalski KE.. Combined intercostal and diaphragm pacing to provide artificial ventilation in patients with tetraplegia. Arch Phys Med Rehabil. 2005;86:1200–7. doi: 10.1016/j.apmr.2004.11.027 - DOI - PubMed
    1. Kawashima Shun, Kohno Tadasu, Fujimori Sakashi, Yokomakura Naoya, Ikeda Takeshi, Harano Takashi, et al. Phrenic nerve reconstruction in complete video-assisted thoracic surgery. Interact CardioVasc Thorac Surg. 2015; 20(1): 54–9. doi: 10.1093/icvts/ivu290 - DOI - PubMed
