. 2020 Apr;35(3):767-775.
doi: 10.1007/s10103-019-02857-7. Epub 2019 Aug 12.

The effects of photodynamic therapy with blue light and papain-based gel associated with Urucum, on collagen and fibroblasts: a spectroscopic and cytotoxicity analysis

Zenildo Santos Silva Jr  1   2   3   4 , Cristiane Miranda França  5   6 , Renato Araújo Prates  5   6 , Sergio Brossi Botta  5   6 , Raquel Agnelli Mesquita Ferrari  5 , Patricia Aparecida Ana  7 , Christiane Pavani  5 , Kristianne Porta Santos Fernandes  5   6 , Daniela de Fátima Teixeira da Silva  5 , Michael R Hamblin  8   9   10 , Sandra Kalil Bussadori  11   12
Affiliations

The effects of photodynamic therapy with blue light and papain-based gel associated with Urucum, on collagen and fibroblasts: a spectroscopic and cytotoxicity analysis

Zenildo Santos Silva Jr et al. Lasers Med Sci. 2020 Apr.

Abstract

Papacarie Duo™ is clinically used and has proven effectiveness; however, it is necessary to improve its antimicrobial action. The combined treatment of Papacarie Duo™ with Urucum (Bixa Orellana) could create a potential tool for dental caries treatment; its extract obtained from the seeds' pericarp contains a water-soluble primary pigment (cis-bixin) with smaller amounts of other carotenoids. The dicarboxylic acid salts of cis-norbixin and trans-norbixin occur in heated alkaline solutions. To analyze the absorption spectra and cytotoxicity (with human dermal fibroblasts) in different concentrations of Urucum, associated or not with Papacarie Duo™, we performed this in vitro study. The effects of pure Urucum, Papacarie Duo™, and PapaUrucum™ on the microstructure of collagen were also analyzed. The application of papain-based gel with Urucum did not present cytotoxicity, its exhibit UV absorption spectrum peak around 460 ± 20 nm. Also, it showed that the compound used did not alter the chemical structure of collagen. Consequently, this product could be used as a chemomechanical method to remove dentin caries as well as being a potential product for antimicrobial photodynamic therapy (aPDT) application.

Keywords: Cytotoxicity; Dentin; Fourier transform infrared spectroscopy; Papain-based gel.

PubMed Disclaimer

Conflict of interest statement

Conflict of interest

The authors declare non-financial interests concerning the work described. M.R. Hamblin is also a present member of the Transdermal Cap, Inc. scientific advisory board.

Figures

Fig. 1
Fig. 1
Chemical structures of Bixa Orellana (Bixin) and papain
Fig. 2
Fig. 2
Shows the peak positions in the UV-Vis and absorption spectra of the annatto solution extracted from the fruit of the Bixa Orellana (pure Urucum), papain gel (Papacarie Duo), and Papain-gel with Urucum (PapaUrucum)
Fig. 3
Fig. 3
Cytotoxicity—MTT assay with pure Urucum and PapaUrucum
Fig. 4
Fig. 4
Organelles localize mitochondria and lysosomes in live cells, MitoTracker Green applied with PapaUrucum and Hoesch® were used. (A1) PapaUrucum 10 μM. (A2) PapaUrucum 20 μM. (A3) PapaUrucum 30 μM. (A4) PapaUrucum 40 μM. To localize lysosomes, LysoTracher® red was used; for internalization, Papa Urucum™. (B1) Papa Urucum 10 μM. (B2) PapaUrucum 20 μM. (B3) PapaUrucum 30 μM. (B4) PapaUrucum 40 μM
Fig. 5
Fig. 5
(A) Mean infrared spectrum of Urucum (Bixa Orellana extract) obtained in region of 4000 to 600 cm−1. The arrows indicate the main peaks of greater intensity. (B) Mean infrared spectra of control and PapaUrucum obtained in the region of 4000 to 600 cm−1. The arrows indicate the main peaks of greater intensity
Fig. 6
Fig. 6
Mean infrared spectra of type-I collagen membranes treated with Milli-Q water, PapaUrucum, and Papacarie Duo™. (A) Region of 4000 to 600 cm−1; (B) Region of 1800 to 700 cm−1
See this image and copyright information in PMC

References

    1. Bussadori SK, Castro LC, Galvão AC (2006) Papain gel: a new chemo-mechanical caries removal agent. J Clin Pediatr Dent 30(2): 115–119 - PubMed
    1. Bussadori S, Guedes C, Hermida Bruno M, Ram D (2008) Chemo-mechanical removal of caries in an adolescent patient using a pa-pain gel: case report. J Clin Pediatr Dent 32(3):177–180 - PubMed
    1. Motta LJ, Bussadori SK, Campanelli AP, Silva AL, Alfaya TA, Godoy CHL et al. (2014) Randomized controlled clinical trial of long-term chemo-mechanical caries removal using PapacarieTM gel. J Appl Oral Sci 22(4):307–313 - PMC - PubMed
    1. Motta LJ, Bussadori SK, Campanelli AP, Silva AL, Alfaya TA, Godoy CHL et al. (2014) Efficacy of Papacarie¯ in reduction of residual bacteria in deciduous teeth: a randomized, controlled clinical trial. Clinics. 69(5):319–322 - PMC - PubMed
    1. Bohari MR, Chunawalla YK, Ahmed BMN (2012) Clinical evaluation of caries removal in primary teethusing conventional, chemomechanical and lasertechnique: an in vivo study. J Contemp Dent Pract 13(1):40–47 - PubMed
