Case Reports
. 2020 Jun 30;20(1):146.
doi: 10.1186/s12893-020-00808-6.

Partial resection of large congenital left ventricular diverticulum in an infant: a case report

Yibing Fang  1 , Qi An  1 , Tianping Yu  2 , Shuhua Luo  3
Affiliations
Case Reports

Partial resection of large congenital left ventricular diverticulum in an infant: a case report

Yibing Fang et al. BMC Surg. .

Abstract

Background: Congenital left ventricular diverticulum is a rare cardiac malformation usually requiring total resection.

Case presentation: This report describes an infant presenting with a large apical diverticulum with a wide ventricle connection. Given the vicinity of the left anterior descending coronary artery to the diverticulum and its wide ventricular connection, partial resection was undertaken. The patient remained asymptomatic with good heart function 8 months after surgery. The last follow-up echocardiography did not demonstrate any significant left ventricular outpouching.

Conclusions: We advocate early treatment of left ventricular diverticulum in children given the risk of spontaneous rupture of diverticulum, sudden death, and other serious complications if left untreated. For small patients with a wide connection of diverticulum to ventricle, partial resection is a safe option with favorable short-term outcomes.

Keywords: Case report; Congenital left ventricular diverticulum; Infant; Partial resection.

PubMed Disclaimer

Conflict of interest statement

The authors declare that they have no competing interests.

Figures

Fig. 1
Fig. 1
Preoperative computed tomography images of the diverticulum. Images showing a protrusion of the left ventricle (arrow) extending beyond the apex, with a wide ventricle connection (a: sagittal view; b: coronal view). A three-dimensional reconstruction showing the morphology (c) and position (d) of the diverticulum
Fig. 2
Fig. 2
Intraoperative exploration (a-c) and partial resection (d) of the diverticulum. Panel b shows, under direct visualization, the ratio between the diverticulum connection with the left ventricular cavity (d2 = 4 cm) and the maximum diameter of the body of the diverticulum (d1 = 3 cm) was 1.3. Abbreviations: LV: left ventricle; RV: right ventricle; LAD: left anterior descending coronary artery; PA: pulmonary artery
Fig. 3
Fig. 3
Histopathology of the resected diverticulum. Shown are the epicardium (external layer, black arrow), myocardium (middle layer, star) and endocardium (inner layer, blue arrow)
See this image and copyright information in PMC

References

    1. Walton-Shirley M, Smith SM, Talley JD. Left ventricular diverticulum: case report and review of the literature. Catheter Cardiovasc Diagn. 1992;26(1):31–33. doi: 10.1002/ccd.1810260108. - DOI - PubMed
    1. Hamaoka K, Onaka M, Tanaka T, Onouchi Z. Congenital ventricular aneurysm and diverticulum in children. Pediatr Cardiol. 1987;8(3):7. doi: 10.1007/BF02263448. - DOI - PubMed
    1. Ohlow M-A, von Korn H, Lauer B. Characteristics and outcome of congenital left ventricular aneurysm and diverticulum: analysis of 809 cases published since 1816. Int J Cardiol. 2015;185:34–45. doi: 10.1016/j.ijcard.2015.03.050. - DOI - PubMed
    1. Malakan Rad E, Awad S, Hijazi ZM. Congenital left ventricular Outpouchings: a systematic review of 839 cases and introduction of a novel classification after two centuries: congenital LV Outpouchings. Congenit Heart Dis. 2014;9(6):498–511. doi: 10.1111/chd.12214. - DOI - PubMed
    1. Masci PG, Pucci A, Fontanive P, Coceani M, Marraccini P, Lombardi M. Double-chambered left ventricle in an asymptomatic adult patient. Eur Heart J Cardiovasc Imaging. 2012;13(3):E1–E3. doi: 10.1093/ejechocard/jer242. - DOI - PubMed
