. 2020 Aug 6;16(1):274.
doi: 10.1186/s12917-020-02485-2.

Evaluation of vacuum phenomenon in dogs with coxofemoral degenerative joint disease using computed tomography

Kanokporn Kanthavichit  1 , Auraiwan Klaengkaew  1 , Naparee Srisowanna  2 , Nardtiwa Chaivoravitsakul  2 , Kongthit Horoongruang  2 , Chutimon Thanaboonnipat  1 , Kumpanart Soontornvipart  1 , Nan Choisunirachon  3
Affiliations

Evaluation of vacuum phenomenon in dogs with coxofemoral degenerative joint disease using computed tomography

Kanokporn Kanthavichit et al. BMC Vet Res. .

Abstract

Background: Degenerative joint disease (DJD) is a common orthopedic lesion in the coxofemoral joint of canine patients. Concurrent with the sign of degeneration, the vacuum phenomenon (VP), or intra-articular gas, has been observed in several locations in both human and canine patients. A cadaveric study described VP in small breed dogs without DJD but with hip laxity. However, none of the canine VP reports mentioned coxofemoral DJD. Therefore, the aim of this retrospective study was to describe the distribution of coxofemoral VP revealed on computed tomography (CT) imaging in canine patients with DJD.

Results: A total of 282 dogs (564 coxofemoral joints), comprising 142 small, 85 large, and 55 medium breeds, were included in the present study. DJD was found in 31.02% of all dogs. The incidence of DJD was highest in large breed dogs (50%), followed by medium (31.81%) and small (19.36%) breed dogs. In addition, VP was detected with CT using the pulmonary window in 31 joints of 25 dogs that received a diagnosis of hip degenerative disease. VP was found most frequently at the laterodorsal area of the acetabulum. The incidences of VP in large, small, and medium breed dogs were 35.94%, 17.14% and 8.33%, respectively. The presence of coxofemoral VP was significantly and positively correlated with DJD (odds ratio = 17.58, 95% CI 2.32-133.42).

Conclusions: The presence of coxofemoral joint DJD and VP was more likely to be detected in large breed dogs, especially in those with established DJD. CT is an advanced diagnostic imaging modality that can be used to reveal VP lesions, most of which are reported at the laterodorsal acetabulum. Further studies, including comparisons of different patient positions, may reveal more information regarding coxofemoral VP.

Keywords: computed tomography; degenerative joint disease; dog; hip; vacuum phenomenon.

PubMed Disclaimer

Conflict of interest statement

The authors declare that they have no competing interests and do not have any potential conflict of interest to declare.

Figures

Fig. 1
Fig. 1
Severe degenerative coxofemoral joint and presence of gas (vacuum phenomenon; arrows) in coxofemoral joint in axial CT images (pulmonary window); a: Dog in prone position; b: Dog in lateral position
Fig. 2
Fig. 2
No coxofemoral joint DJD lesion (Grade 0 or G0) in axial CT images (bone window): Femoral head and acetabulum are congruent and no lesion of DJD
Fig. 3
Fig. 3
Developing coxofemoral joint DJD lesion (Grade 1 or G1) in axial CT images (bone window): Osteophyte formation at dorsal femoral head
Fig. 4
Fig. 4
Established coxofemoral joint DJD lesion (Grade 2 or G2) in axial CT images (bone window): Severe sclerosis of head and acetabulum with femoral head and acetabulum incongruency
See this image and copyright information in PMC

References

    1. Bland SD. Canine osteoarthritis and treatments: a review. Vet Sci Dev. 2005;5(5931):84–9.
    1. Smith GK, Mayhew PD, Kapatkin AS, McKelvie PJ, Shofer FS, Gregor TP. Evaluation of risk factors for degenerative joint disease associated with hip dysplasia in German Shepherd Dogs, Golden Retrievers, Labrador Retrievers, and Rottweilers. J Am Vet Med Assoc. 2001;219(12):1719–24. doi: 10.2460/javma.2001.219.1719. - DOI - PubMed
    1. Rettenmaier J, Keller G, Lattimer J, Corley E, Ellersieck M. Prevalence of canine hip dysplasia in a veterinary teaching hospital population. Vet Radiol Ultrasound. 2002;43(4):313–8. doi: 10.1111/j.1740-8261.2002.tb01010.x. - DOI - PubMed
    1. Clements DN, Carter SD, Innes JF, Ollier WE. Genetic basis of secondary osteoarthritis in dogs with joint dysplasia. Am J Vet Res. 2006;67(5):909–18. doi: 10.2460/ajvr.67.5.909. - DOI - PubMed
    1. Arnbjerg J. Hip Joint Laxity in Small Dog Breeds A Radiological Study. SOJ Vet Sci. 2017;3:1–5.
