Case Reports
. 2020 Sep 14;15(1):254.
doi: 10.1186/s13019-020-01278-w.

Left upper lung cancer with persistent left superior vena cava and left azygos vein: a case report

Zhongben Tang  1 , Yin Teng  2 , Jian Li  2 , Xiaojun Du  2 , Jiarong Xiao  2 , Gongshun Tang  3
Affiliations
Case Reports

Left upper lung cancer with persistent left superior vena cava and left azygos vein: a case report

Zhongben Tang et al. J Cardiothorac Surg. .

Abstract

Background: With the popularization of thoracoscopic surgery, more and more macrovascular malformations have been reported. Understanding some vascular malformations with relatively fixed anatomical site and their range of drainage could avoid severe complications during the surgery. Persistent left superior vena cava (PLSVC) is a common thoracic vascular malformation, and is always combined with other cardiovascular dysplasia. As for the patient with upper left lung cancer in this case, he had PLSVC and left azygos vein, and non-metastatic enlargement of the lymph nodes at the same time, which had influenced the decisions on surgery and treatment. We made a summary of experience regarding this.

Case presentation: A 46-years-old male patient, his CT found a space-occupying lesion in the superior lobe of the left lung. The chest CT showed that the patient had PLSVC and left azygos vein, and multiple enlarged lymph nodes in the mediastinum. The patient received thoracoscopic upper left lung lobectomy and lymph node dissection. It was discovered that the left azygos vein had a concealed form, which influenced the lymph node dissection. The post-surgery pathology showed that there was squamous cell carcinoma in the upper left lung (pT2bN0M0 p Phase IIA) and no cancer metastasis with the lymph nodes. The patient had a good post-surgery recovery.

Conclusions: PLSVC is not rare, and is always combined with other vascular malformations. If discovering PLSVC before surgery, we suggest completing chest enhanced CT and vascular reconstruction, to find out other cardiovascular malformations that may exist. Left azygos vein is a rare vascular malformation, but it has a relatively fixed anatomical site, and always co-exists with PLSVC, therefore, understanding anatomy of left azygos vein is good for preventing accidental damage. Especially when performing surgery above the left pulmonary artery trunk, attention shall be paid to preventing damage to the left azygos vein. In addition, as for the patient with the diagnosis of lung cancer before surgery, it is not reliable to judge whether there is metastasis or not merely according to the size of the lymph nodes, instead, PET-CT or needle biopsy is recommended.

Keywords: Left azygos vein; Lung cancer; Persistent left superior vena cava; Surgery.

PubMed Disclaimer

Conflict of interest statement

We declare that we have no competing interests.

Figures

Fig. 1
Fig. 1
Left upper lung tumor
Fig. 2
Fig. 2
Persistent left superior vena cava(PLSVC) and left azygos vein (Chest CT which was shot 8 months after surgery). The left azygos vein is not easy to be detected before surgery.(red arrow: left azygos vein, yellow arrow: PLSVC, blue arrow: left pulmonary artery trunk)
Fig. 3
Fig. 3
Left azygos vein
Fig. 4
Fig. 4
Lymph nodes of Group 5,6 and 10. The maximum diameter of lymph nodes of Group 5 was 2.5 cm
See this image and copyright information in PMC

Similar articles

See all similar articles

References

    1. Povoski SP, Khabiri H. Persistent left superior vena cava: Review of the literature, clinical implications, and relevance of alterations in thoracic central venous anatomy as pertaining to the general principles of central venous access device placement and venography in cancer patients. World J Surg Oncol. 2011;9:173. doi: 10.1186/1477-7819-9-173. - DOI - PMC - PubMed
    1. Li J, Mao Q, Sun Z, Li Q. A rare variant between the left superior vena cava and the azygos vein. Surg Radiol Anat. 2017;39(1):107–109. doi: 10.1007/s00276-016-1705-y. - DOI - PubMed
    1. Prasanna LC, Thomas HR, Das A, Kumar R. Left-Sided Persistent Superior Vena Cava with Superior Hemiazygos Arch. J Clin Diagn Res. 2016;10(5):AD03–AD05. - PMC - PubMed
    1. Uemura M, Takemura A, Ehara D, Yasumitsu H, Ohnishi Y, Suwa F. Left superior vena cava with left azygos vein. Okajimas Folia Anat Jpn. 2009;86(2):55–60. doi: 10.2535/ofaj.86.55. - DOI - PubMed
    1. GLASGOW EF Persistent left superior vena cava with bilateral azygos system in an adult. Br Heart J. 1963;25(2):264–266. doi: 10.1136/hrt.25.2.264. - DOI - PMC - PubMed
