Case Reports
. 2020 Oct 9;99(41):e22491.
doi: 10.1097/MD.0000000000022491.

Myocardial bridging-an unusual cause of Wellens syndrome: A case report

Anamaria Avram  1   2 , Valentin Chioncel  1   2 , Suzana Guberna  1   2 , Irina Cuciureanu  1   2 , Radu Constantin Brezeanu  1   2 , Catalina Liliana Andrei  1   2 , Crina Sinescu  1   2
Affiliations
Case Reports

Myocardial bridging-an unusual cause of Wellens syndrome: A case report

Anamaria Avram et al. Medicine (Baltimore). .

Abstract

Rationale: Coronary chest pain is usually ischemic in etiology and has various electrocardiographic presentations. Lately, it has been recognized that myocardial bridging (MB) with severe externally mechanical compression of an epicardial coronary artery during systole may result in myocardial ischemia. Such a phenomenon can be associated with chronic angina pectoris, acute coronary syndromes (ACS), coronary spasm, ventricular septal rupture, arrhythmias, exercise-induced atrioventricular conduction blocks, transient ventricular dysfunction, and sudden death.

Patient concerns: We report the case of a 58-year-old woman presenting with recurrent episodes of constrictive chest pain during exercise within the last 2 weeks. Except for obesity, general and cardiovascular clinical examination on admission were normal.

Diagnoses: The resting 12 lead electrocardiogram (ECG) revealed changes typically for Wellens syndrome. High-sensitive cardiac troponin I was normal. We established the diagnosis of low-risk non-ST-segment elevation acute coronary syndrome with a Global Registry of Acute Coronary Events risk score of 92 points.

Interventions: The patient underwent coronary angiography, who showed subocclusive dynamic obstruction of the left anterior descending artery due to MB.

Outcomes: The patient was managed conservatively. Her hospital course was uneventful and she was discharged on pharmacological therapy (clopidogrel, bisoprolol, amlodipine, atorvastatin, and metformin) with well-controlled symptoms on followup.

Lessons: MB is an unusual cause of myocardial ischemia. Wellens syndrome is an unusual presentation of ACS. We present herein a rare case of Wellens syndrome caused by MB. This case highlights the importance of subtle and frequently overseen ECG findings when assessing patients with chest pain and second, the importance of considering nonatherosclerotic causes for ACS.

PubMed Disclaimer

Figures

Figure 1
Figure 1
ECG on admission showing type A Wellens pattern. ECG = electrocardiogram.
Figure 2
Figure 2
Coronary angiography, incidence left anterior oblique (LAO) during diastole (A) and systole (B).
Figure 3
Figure 3
Coronary angiography, incidence right anterior oblique (RAO) during diastole (A) and systole (B).
Figure 4
Figure 4
ECG taken the next day after coronary angiography showing diffuse T waves flattening. ECG = electrocardiogram.
See this image and copyright information in PMC

References

    1. Alegria JR, Herrmann J, Holmes DR, Jr, et al. . Myocardial bridging. Eur Heart J 2005;26:1159–68. - PubMed
    1. de Zwaan C, Bär FW, Wellens HJ. Characteristic electrocardiographic pattern indicating a critical stenosis high in left anterior descending coronary artery in patients admitted because of impending myocardial infarction. Am Heart J 1982;103(4 pt 2):730–6. - PubMed
    1. Karadžić M, Vučković-Filipović J, Davidović G, et al. . The “widow maker” warning sign or Wellens’ syndrome: a case report. Arch Biol Sci 2012;64:733–8.
    1. de Zwaan C, Bär FW, Janssen JH, et al. . Angiographic and clinical characteristics of patients with unstable angina showing an ECG pattern indicating critical narrowing of the proximal LAD coronary artery. Am Heart J 1989;117:657–65. - PubMed
    1. Kobayashi A, Misumida N, Aoi S, et al. . Prevalence and clinical implication of Wellens’ sign in patients with non-ST-segment elevation myocardial infarction. Cardiol Res 2019;10:135–41. - PMC - PubMed
