Review
. 2021 Mar 29;16(1):60.
doi: 10.1186/s13019-021-01420-2.

VATS right posterior segmentectomy with anomalous bronchi and pulmonary vessels: a case report and literature review

Jianbin Zhang #  1 , Yilv Zhu #  2 , Hongwei Li  3 , Caihua Yu  1 , Weiwei Min  1
Affiliations
Review

VATS right posterior segmentectomy with anomalous bronchi and pulmonary vessels: a case report and literature review

Jianbin Zhang et al. J Cardiothorac Surg. .

Abstract

Background: Anatomic variation may increase the difficulty and risk of anatomic segmentectomy. The preoperative three-dimensional computed tomography bronchography and angiography (3D-CTBA) can provide a detailed model of the segmental structure, and contribute to precise and safe segmentectomy.

Case presentation: This is a case of anomalous bronchi and pulmonary vessels in the right upper posterior segment (RS2). Under the guidance of 3D-CTBA, anatomic RS2 segmentectomy was performed accurately and safely. The postoperative condition was uneventful.

Conclusions: This rare case highlights the importance of 3D-CTBA to guild accurate segmentectomy with anatomic variation.

Keywords: Segmentectomy; Three-dimensional computed tomography bronchography and angiography (3D-CTBA); Video-assisted thoracoscopic surgery (VATS).

PubMed Disclaimer

Conflict of interest statement

The authors declare that they have no competing interests.

Figures

Fig. 1
Fig. 1
The preoperative computed tomography scanning. A 7-mm ground-glass nodule was identified at the posterior segment of the right upper lobe (arrow), the CT value was -400HU
Fig. 2
Fig. 2
The three-dimensional computed tomography bronchography and angiography. The apical subsegmental bronchi(B1a and B1b) originated from the posterior segmental bronchus (B2) and the anterior segmental bronchus (B3) respectively; The right upper pulmonary artery shared trunk without posterior ascending artery (Asc.A2); The right upper pulmonary vein had no central vein, with only one posterior intrasegmental vein(V2t), the other two veins pointed to the intersegmental plane respectively. a Posterior view; b Lateral view
Fig. 3
Fig. 3
The QR code of Video. VATS right posterior segmentectomy and lymph node sampling
Fig. 4
Fig. 4
The intraoperative view of the posterior segment of the right upper lobe. a Exposed the posterior segmental artery after releasing the segmental hilum sufficiently; b The structure of lung segmental hilum after resection
Fig. 5
Fig. 5
The chest radiograph on the 2nd postoperative day. The incisal margin of the segment displayed no obvious exudation (arrow)
See this image and copyright information in PMC

References

    1. Nakazawa S, Shimizu K, Mogi A, Kuwano H. VATS segmentectomy: past, present, and future. Gen Thorac Cardiovasc Surg. 2018;66(2):81–90. doi: 10.1007/s11748-017-0878-6. - DOI - PubMed
    1. Sato Y, Fujimoto D, Morimoto T, Uehara K, Nagata K, Sakanoue I, Hamakawa H, Takahashi Y, Imai Y, Tomii K. Natural history and clinical characteristics of multiple pulmonary nodules with ground glass opacity. Respirology. 2017;22(8):1615–1621. doi: 10.1111/resp.13089. - DOI - PubMed
    1. Aragaki M, Iimura Y, Yoshida Y, Hasegawa N. Anomalous V(2) of the left pulmonary vein detected using three-dimensional computed tomography in a patient with lung cancer: a case report. Int J Surg Case Rep. 2017;37:208–210. doi: 10.1016/j.ijscr.2017.06.046. - DOI - PMC - PubMed
    1. Ohtaka K, Iwashiro N, Watanabe K, Mizota T, Takahashi R, Suzuoki M, Komuro K, Ohara M, Kaga K, Matsui Y. A left lung abscess with a displaced subsegmental bronchus and anomalous pulmonary artery and vein: a case report. Surg Case Rep. 2019;5(1):66. doi: 10.1186/s40792-019-0627-4. - DOI - PMC - PubMed
    1. Qi W, Yang F, Liu H, Sun Y. Thoracoscopic right apical segmentectomy for lung cancer with tracheal bronchus and variable pulmonary vein: a case report and literature review. J Int Med Res. 2020;48(8):300060520947935. doi: 10.1177/0300060520947935. - DOI - PMC - PubMed
