Skull fracture and epidural hematoma caused by use of a Mayfield skull clamp in an adult patient with chronic hemodialysis: a case report

Abstract

Background: Mayfield skull clamps are widely used and indispensable in current neurosurgery. Complications such as skull fractures or intracranial hematoma from using a Mayfield skull clamp have largely been reported in the pediatric population, are likely related to the relative thinness of the skull, such as in patients with hydrocephalus, and are extremely rare in adults. Here, we report a case of skull fracture and epidural hematoma caused by a Mayfield skull clamp used for posterior decompression surgery in an adult patient with chronic hemodialysis.

Case presentation: A 67-year-old Asian male patient with a history of dialysis-dependent chronic renal failure over 36 years suffered from severe cervical myelopathy. Neurological examination and radiographic images revealed cervical spondylotic myelopathy due to dialysis-related spondyloarthropathy. Laminoplasty was planned on patient consent. A Mayfield skull clamp was applied with the patient supine. Torque was applied to the screws with gentle care, but there was no resistance and it was not easy to reach the standard 60 lb (267 N) to 80 lb (356 N). Because a skull fracture was suspected, we canceled the surgery. Emergency head computed tomography showed depressed skull fractures underlying the single-pin sites with an associated epidural hematoma. The fractures and epidural hematoma were treated conservatively, and spontaneous resolution of the hematoma was confirmed. Cervical laminoplasty was performed successfully using a mask-type head holder on the subsequent day.

Conclusions: As a precaution for fractures and epidural hematoma in neurosurgical patients with bone fragility or a thin skull, use of a mask-type fixing device or halo ring is recommended.

Keywords: Adult patient; Case report; Epidural hematoma; Mayfield skull clamp; Skull fracture.

Fig. 1

a Computed tomography (CT) showing an extradural amyloid deposit and hypertrophied ligament, which are characteristic findings for dialysis-related spondyloarthropathy. b Magnetic resonance imaging (MRI) showing multilevel spinal cord compression at the C3–C6 levels and T2-weighted hyperintensity of the spinal cord at the C3–C4 level

Fig. 2

Emergency head computed tomography (CT) showing depressed skull fractures underlying the single-pin sites (a, b) with an associated epidural hematoma on the left (Lt.) side (c)

Fig. 3

Postoperative magnetic resonance imaging (MRI) confirming successful decompression of the spinal cord
