. 2021 Apr 7;14(8):1811.
doi: 10.3390/ma14081811.

Effect of Acetylated SEBS/PP for Potential HVAC Cable Insulation

Peng Zhang  1   2 , Xuan Wang  1   2 , Jiaming Yang  1   2 , Yongqi Zhang  1   2
Affiliations

Effect of Acetylated SEBS/PP for Potential HVAC Cable Insulation

Peng Zhang et al. Materials (Basel). .

Abstract

Blending polypropylene (PP) with thermoplastic elastomer SEBS can effectively improve the mechanical toughness of PP, thus leading to the promise of SEBS/PP as the primary insulation material for high voltage alternating current (HVAC) cables. However, the growth of electrical trees during cable operation limits the application of SEBS/PP. In this paper, acetylation reaction is used to construct acetophenone group at the end of the benzene ring on SEBS so that it has the effect of both a toughening agent and a voltage stabilizer. Then PP was melt blended with acetylated SEBS (Ac-SEBS), and the effects of Ac-SEBS on the mechanical properties, electrical tree resistance, alternating current (AC) breakdown strength, and dielectric spectrum of PP were mainly investigated with reference to PP and SEBS/PP. The results showed that Ac-SEBS with 30% content could enhance the mechanical toughness of PP and improve the electrical tree resistance and AC breakdown strength of SEBS/PP. The AC breakdown field strength of Ac-SEBS/PP reached the highest when the acetylation level was 4.6%, which was 9.2% higher than that of SEBS/PP. At this time, Ac-SEBS was also able to absorb high-energy electrons through the keto-enol interchange isomerization reaction, which inhibited the initiation and growth of electric trees and caused the development of electric dendrites in a jungle-like manner. Moreover, the dielectric loss factor of AC-SEBS/PP in power frequency is within the allowable range of industry. Therefore, Ac-SEBS/PP is expected to be applied to HVAC cables, thus further improving the efficiency of HVAC power transmission.

Keywords: breakdown field strength; electrical tree; polypropylene; thermoplastic elastomer; voltage stabilizer.

PubMed Disclaimer

Conflict of interest statement

The authors declare no conflict of interest.

Figures

Figure 1
Figure 1
The preparation of Ac-SEBS.
Figure 2
Figure 2
Infrared spectra of SEBS and Ac-SEBS.
Figure 3
Figure 3
1H NMR spectra of SEBS and Ac-SEBS.
Figure 4
Figure 4
SEM images of Ac-SEBS/PP composites with different acetylation degrees of SEBS: (a): PP; (b): 0%; (c): 2%; (d): 4.6%; (e): 6%; (f): 12%.
Figure 4
Figure 4
SEM images of Ac-SEBS/PP composites with different acetylation degrees of SEBS: (a): PP; (b): 0%; (c): 2%; (d): 4.6%; (e): 6%; (f): 12%.
Figure 5
Figure 5
Stress-strain curve of PP and its composites.
Figure 6
Figure 6
AC breakdown field strength of PP and its composites.
Figure 7
Figure 7
Weibull distribution of the electrical tree initiation voltage of PP and its composites.
Figure 8
Figure 8
Relationship between the tree length and the treeing time.
Figure 9
Figure 9
The electrical tree microscopic morphology of PP and Ac-SEBS/PP with different degrees of acetylation when the voltage is applied for 7200 s (a): PP, (b): PP/SEBS; (c): 2%; (d): 4.6%; (e): 6%; (f): 12%.
Figure 10
Figure 10
The dielectric constant spectrum of PP and its composites.
Figure 11
Figure 11
Dielectric loss spectrum of PP and its composite materials.
