. 2021 Sep 4;10(9):1073.
doi: 10.3390/antibiotics10091073.

New Technique for Custom-Made Spacers in Septic Two-Stage Revision of Total Hip Arthroplasties

Moritz Mederake  1 , Ulf Krister Hofmann  1 , Bernd Fink  2   3
Affiliations

New Technique for Custom-Made Spacers in Septic Two-Stage Revision of Total Hip Arthroplasties

Moritz Mederake et al. Antibiotics (Basel). .

Abstract

The choice of spacer in the interim phase of two-stage revision hip arthroplasty is crucial. Conventional concepts like a Girdlestone situation, handformed or preformed bone cement spacers show complications like soft-tissue contractions, abrasion of bone cement particles, dislocation, breakage and a low level of mobility in the interim phase. To address these disadvantages, the senior author developed a new technique for custom-made spacers in septic two-stage revision of total hip arthroplasties using prosthetic implants with individualized antibiotic mixture in the cement applying a mechanical inferior cementation method. The aim of this study was to evaluate the results of these spacers with respect to their non-inferiority in terms of reinfection and survival-rate of the new implant and to describe the complications associated with this procedure. Our collective consisted of 130 patients with a median follow-up of nearly five years. With a reinfect-free rate of 92% and a spacer-related complication rate of 10% (8% articular dislocation, 1% periprosthetic joint fracture, 1% breakage), this procedure seems to be safe and superior regarding complications compared to conventional concepts. Further studies are necessary to show the clinical benefit of this procedure.

Keywords: spacer-periprosthetic joint infection-hip arthroplasty-two-stage revision-antibiotic therapy-orthopedic infections-bone and joint infections.

PubMed Disclaimer

Conflict of interest statement

The authors declare no conflict of interest.

Figures

Figure 1
Figure 1
Case with an endofemoral explantation followed by the interim prosthesis and reimplantation. (a): Preoperative situation with infected Zweimueller stem. (b): After endofemoral explantation of the infected prosthesis, the interim prosthesis was implanted consisting of a cemented stem and acetabular a Ganz-ring with a Müller flat-profile cup (ZimmerBiomet, Winterthur, Switzerland). (c): Situation after reimplantation of the definitive prosthesis consisting of Allofit S-cup and Revitan stem (ZimmerBiomet, Winterthur, Switzerland).
Figure 2
Figure 2
Case with a transfemoral explantation because of a fully osteointegrated prosthetic stem, which was not possible to explant endofemorally. (a): Preoperative situation with infected CLS-stem (ZimmerBiomet, Winterthur, Switzerland). (b): After transfemoral explantation of the infected prosthesis the interim prosthesis was implanted consisting of a Weber-Stem and acetabular a Ganz-ring with a Müller flat-profile cup (ZimmerBiomet, Winterthur, Switzerland). The Ganz-ring was fixed with only three screws. The transfemoral flap was refixed with 1.5 mm diameter cerclages. (c): Situation after reimplantation of the definitive prosthesis consisting of an Allofit S-cup and a Revitan stem (ZimmerBiomet, Winterthur, Switzerland).
Figure 3
Figure 3
Kaplan–Meier curve for the proportion of patients free from reinfection.
See this image and copyright information in PMC

Similar articles

See all similar articles

Cited by

See all "Cited by" articles

References

    1. Fink B. Revision of late periprosthetic infections of total hip endoprostheses: Pros and cons of different concepts. Int. J. Med. Sci. 2009;6:287–295. doi: 10.7150/ijms.6.287. - DOI - PMC - PubMed
    1. Li C., Renz N., Trampuz A. Management of Periprosthetic Joint Infection. Hip Pelvis. 2018;30:138–146. doi: 10.5371/hp.2018.30.3.138. - DOI - PMC - PubMed
    1. Pulido L., Ghanem E., Joshi A., Purtill J.J., Parvizi J. Periprosthetic joint infection: The incidence, timing, and predisposing factors. Clin. Orthop. Relat. Res. 2008;466:1710–1715. doi: 10.1007/s11999-008-0209-4. - DOI - PMC - PubMed
    1. Cui Q., Mihalko W.M., Shields J.S., Ries M., Saleh K.J. Antibiotic-impregnated cement spacers for the treatment of infection associated with total hip or knee arthroplasty. J. Bone Jt. Surg. Am. 2007;89:871–882. doi: 10.2106/00004623-200704000-00026. - DOI - PubMed
    1. Garvin K.L., Hanssen A.D. Infection after total hip arthroplasty. Past, present, and future. J. Bone Jt. Surg. Am. 1995;77:1576–1588. doi: 10.2106/00004623-199510000-00015. - DOI - PubMed
