Effect of Leg Extension Angle on Knee Flexion Angle during Swing Phase in Post-Stroke Gait

Abstract

Background and Objectives: Leg extension angle is important for increasing the propulsion force during gait and is a meaningful indicator for evaluating gait quality in stroke patients. Although leg extension angle during late stance might potentially also affect lower limb kinematics during the swing phase, the relationship between these two remains unclear. This study aimed to investigate the relationship between leg extension angle and knee flexion angle during pre-swing and swing phase in post-stroke gait. Materials and Methods: Twenty-nine stroke patients walked along a 16 m walkway at a self-selected speed. Tilt angles and acceleration of pelvis and paretic lower limb segments were measured using inertial measurement units. Leg extension angle, consisting of a line connecting the hip joint with the ankle joint, hip and knee angles, and increments of velocity during pre-swing and swing phase were calculated. Correlation analysis was conducted to examine the relationships between these parameters. Partial correlation analysis adjusted by the Fugl-Meyer assessment-lower limb (FMA-LL) was also performed. Results: On the paretic side, leg extension angle was positively correlated with knee flexion angle during the swing phase (r = 0.721, p < 0.001) and knee flexion angle and increments of velocity during the pre-swing phase (r = 0.740-0.846, p < 0.001). Partial correlation analysis adjusted by the FMA-LL showed significant correlation between leg extension angle and knee flexion angle during the swing phase (r = 0.602, p = 0.001) and knee flexion angle and increments of velocity during the pre-swing phase (r = 0.655-0.886, p < 0.001). Conclusions: Leg extension angle affected kinematics during the swing phase in post-stroke gait regardless of the severity of paralysis, and was similar during the pre-swing phase. These results would guide the development of effective gait training programs that enable a safe and efficient gait for stroke patients.

Keywords: gait analysis; inertial measurement units; knee flexion angle; leg extension angle; stroke.

Figure 1

Relationships between leg extension angle and Fugl-Meyer assessment-lower limb (FMA-LL), gait parameters at late stance and swing phase on the paretic side. (A) Leg extension angle vs. FMA-LL. (B) Leg extension angle vs. knee flexion at pre-swing (PSw). (C) Leg extension angle vs. increments of velocity at late stance phase. (D) Leg extension angle vs. knee flexion at swing phase (Sw).
