. 2023 Feb 21;6(1):7.
doi: 10.1186/s42155-023-00351-4.

A technical review of bail-out procedures to place Najuta stent-graft into the ascending aorta

Raffaella Berchiolli #  1 , Nicola Troisi #  2 , Giulia Bertagna  1 , Andrea Colli  3 , Laura Besola  3 , Roberto Silingardi  4 , Gioele Simonte  5 , Giacomo Isernia  5 ; Italian Najuta registry collaborators
Collaborators, Affiliations

A technical review of bail-out procedures to place Najuta stent-graft into the ascending aorta

Raffaella Berchiolli et al. CVIR Endovasc. .

Abstract

Background: The Najuta stent-graft (Kawasumi Laboratories Inc., Tokyo, Japan) is usually easily advanced to the correct deployment position in the ascending aorta thanks to the pre-curved delivery J-sheath with all fenestrations automatically oriented towards the supra-aortic vessels. Aortic arch anatomy and delivery system stiffness could however represent limitations for proper endograft advancement, especially when the aortic arch bends sharply. The aim of this technical note is to report a series of bail-out procedures that could be useful to overcome the difficulties encountered during the Najuta stent-graft advancement up to the ascending aorta.

Main body: The insertion, positioning and deployment of a Najuta stent-graft requires a through-and-through guidewire technique using a .035″ 400 cm hydrophilic nitinol guidewire (Radifocus™ Guidewire M Non-Vascular, Terumo Corporation, Tokyo, Japan) with right brachial and both femoral accesses. When standard maneuver to put the endograft tip into the aortic arch, some bail-out procedures can be applied to obtain proper positioning. Five techniques are described into the text: positioning of a coaxial extra-stiff guidewire; positioning of a long introducer sheath down to the aortic root from the right brachial access; inflation of a balloon inside the ostia of the supra-aortic vessels; inflation of a balloon inside the aortic arch (coaxial to the device); and transapical access technique. This is a troubleshooting guide for allowing physicians to overcome various difficulties with the Najuta endograft as well as for other similar devices.

Short conclusion: Technical issues in advancing the delivery system of Najuta stent-graft could occur. Therefore, the rescue procedures described in this technical note could be useful to guarantee the correct positioning and deployment of the stent-graft.

Keywords: Aortic arch; Najuta stent-graft; Thoracic endovascular aortic repair (TEVAR).

PubMed Disclaimer

Conflict of interest statement

Giacomo Isernia is consultant for SB-Kawasumi Laboratories Inc., Kanagawa, Japan; Giacomo Isernia, Gioele Simonte, and Roberto Silingardi are consultant for Penumbra Europe GmbH, Berlin, Germany (distributor in Europe for SB-Kavasumi Laboratories Inc.). The other authors have no conflicts of interest related to the article.

Figures

Fig. 1
Fig. 1
Coaxial extra-stiff guidewire put inside the ascending aorta (arrow)
Fig. 2
Fig. 2
Long introducer sheath from right brachial access down to the aortic root (arrow)
Fig. 3
Fig. 3
Balloon inflated inside the ostia of the supra-aortic vessels: a innominate trunk (arrow); b left subclavian artery (arrow)
Fig. 4
Fig. 4
Balloon inflated inside the aortic arch (arrow)
See this image and copyright information in PMC

References

    1. Blanco Amil CL, Mestres Alomar G, Guarnaccia G, Luoni G, Yugueros Castellnou X, Vigliotti RC, et al. The initial experience on branched and fenestrated Endografts in the aortic arch. A systematic review. Ann Vasc Surg. 2021;75:29–44. doi: 10.1016/j.avsg.2021.03.024. - DOI - PubMed
    1. Colli A, Manzan E, Fabio FZ, Sarais C, Pittarello D, Speziali G, et al. TEE-guided transapical beating-heart neochord implantation in mitral regurgitation. JACC Cardiovasc Imaging. 2014;7:322–323. doi: 10.1016/j.jcmg.2014.01.003. - DOI - PubMed
    1. Fernández-Alonso L, Fernández Alonso S, Martínez Aguilar E, Santamarta Fariña E, Alegret Solé J, Atienza Pascual M, et al. Fenestrated and scalloped endovascular grafts in zone 0 and zone 1 for aortic arch disease. Ann Vasc Surg. 2020;69:360–365. doi: 10.1016/j.avsg.2020.06.009. - DOI - PubMed
    1. Isernia G, Simonte G, Orrico M, Silingardi R, Gaggiano A, Covic T et al (2023) Preliminary results from an Italian National Registry on the outcomes of the Najuta fenestrated aortic arch endograft. J Vasc Surg 2023. 10.1016/j.jvs.2022.12.059 in press - PubMed
    1. Mastrorilli D, Mezzetto L, Scorsone L, Leone N, Gennai S, Veraldi E, et al. Sheath-anchoring for rail guidewire technique to advance and deploy thoracic endograft in hostile anatomy. Ann Vasc Surg. 2022;80:393. doi: 10.1016/j.avsg.2021.09.033. - DOI - PubMed
