Outcome of buttress plate-nail construct used for reconstruction of broken lateral wall in intertrochanteric fractures

Abstract

Purpose: Intramedullary implants are well accepted fixation of all types of intertrochanteric (IT) fractures, both stable and unstable types. Intramedullary nails have an ability to effectively support the posteromedial part, but fail to buttress the broken lateral wall requiring lateral augmentation. The aim of this study was to evaluate the outcome of proximal femoral nail augmented with trochanteric buttress plate for broken lateral wall with IT fractures, which was fixed to the femur through hip screw and anti-rotation screw nail.

Methods: Of 30 patients, 20 had Jensen-Evan type III and 10 had type V fractures. Patients with IT fracture of broken lateral wall and aged more than 18 years, in whom satisfactory reduction was achieved by closed methods, were included in the study. Patients with pathologic or open fractures, polytrauma, prior hip surgery, non-ambulatory prior to surgery, and those who refused to participate were excluded. The operative time, blood loss, radiation exposure, quality of reduction, functional outcome, and union time were evaluated. All data were coded and recorded in Microsoft Excel spread sheet program. SPSS 20.0 was used for data analysis and normality of the continuous data was checked using Kolmogorv Smirnov test.

Results: The mean age of patients in the study was 60.3 years. The mean duration of surgery (min), mean intra-operative blood loss (mL) and mean number of exposures were 91.86 ± 12.8 (range 70 - 122), 144.8 ± 3.6 (range 116 - 208), and 56.6 (range 38 - 112), respectively. The mean union time was 11.6 weeks and the mean Harris hip score was 94.1.

Conclusion: Lateral trochanteric wall in IT fractures is significantly important, and needs to be reconstructed adequately. Nail-plate construct of trochanteric buttress plate fixed with hip screw and anti-rotation screw of proximal femoral nail can be successfully used to augment, fix or buttress the lateral trochanteric wall giving excellent to good results of early union and reduction.

Keywords: Intertrochanteric fracture; Intramedullary nail; Lateral trochanteric wall; Proximal femoral nail; Trochanteric buttress plate.

Fig. 1

Intraoperative photos. (A) and (B) TBP plate application with proximal femoral nailing showing removal of detachable arm and sliding of trochanteric buttress plate over guide pins. (C) and (D) Fluoroscopic view of TBP plate flushed to the bone with hip and antirotation screw and final fixation with additional screws proximally and distally.
