Towards population-independent, multi-disease detection in fundus photographs

Abstract

Independent validation studies of automatic diabetic retinopathy screening systems have recently shown a drop of screening performance on external data. Beyond diabetic retinopathy, this study investigates the generalizability of deep learning (DL) algorithms for screening various ocular anomalies in fundus photographs, across heterogeneous populations and imaging protocols. The following datasets are considered: OPHDIAT (France, diabetic population), OphtaMaine (France, general population), RIADD (India, general population) and ODIR (China, general population). Two multi-disease DL algorithms were developed: a Single-Dataset (SD) network, trained on the largest dataset (OPHDIAT), and a Multiple-Dataset (MD) network, trained on multiple datasets simultaneously. To assess their generalizability, both algorithms were evaluated whenever training and test data originate from overlapping datasets or from disjoint datasets. The SD network achieved a mean per-disease area under the receiver operating characteristic curve (mAUC) of 0.9571 on OPHDIAT. However, it generalized poorly to the other three datasets (mAUC < 0.9). When all four datasets were involved in training, the MD network significantly outperformed the SD network (p = 0.0058), indicating improved generality. However, in leave-one-dataset-out experiments, performance of the MD network was significantly lower on populations unseen during training than on populations involved in training (p < 0.0001), indicating imperfect generalizability.

Figure 1

An overview of our proposed study. (a) A single-dataset network trained on a single homogeneous dataset. (b) A multi-dataset network trained on multiple heterogeneous datasets. (c) Assessing deep learning algorithms generality for data coming from an in-domain or out-of-domain distribution.

Figure 2

ROC curves for the SD network and the MD network trained on all the datasets ($K=4).$ The left column shows the ROC curves for the SD network and the right column shows the ROC curves for the MD network trained on all the datasets ($K=4)$ on the OPHDIAT test subset (a, b), the OphtaMaine test subset (c, d), the RIADD test subset (e, f) and the ODIR test subset (g, h).

Figure 3

ROC curves for the MD network when a dataset is included for training and when it is left out. On each test subset, the left column shows the ROC curves for the MD network when the associated training/validation subsets are left out and the right column shows the ROC curves when the associated training/validation subsets are included for training the MD network. The ROC curves are shown on the OPHDIAT test subset (a, b), the OphtaMaine test subset (c, d), the RIADD test subset (e, f) and the ODIR test subset (g, h).
