Review
. 2023 Jul 19:60:28-32.
doi: 10.1016/j.ejvsvf.2023.06.001. eCollection 2023.

Endovascular Graft Suprarenal Bare Metal Stent Separation After Endovascular Aneurysm Repair: Case Reports and Literature Review

Jeffrey M A van der Krogt  1 , Anne C van Erp  1 , Stefan P M Smorenburg  1   2 , Martine C M Willems  1 , Johanna H Nederhoed  1   2
Affiliations
Review

Endovascular Graft Suprarenal Bare Metal Stent Separation After Endovascular Aneurysm Repair: Case Reports and Literature Review

Jeffrey M A van der Krogt et al. EJVES Vasc Forum. .

Abstract

Objective: Suprarenal bare metal stent separation is a rare complication after endovascular aneurysm repair. In this report, two new cases of this type of device failure are presented and the literature is reviewed to identify similar cases and evaluate associated clinical characteristics.

Methods: A literature search was conducted in March 2022 using PubMed, Embase, and The Cochrane Library, with MeSH terms including aortic aneurysm, stents, and device failure. Two authors independently selected studies eligible for inclusion.

Results: Twelve patients with endovascular graft suprarenal bare metal stent separation were identified. Endovascular aneurysm repair (EVAR) devices were implanted between May 1996 and November 2017. Suprarenal bare metal stent separation was detected after a median duration of five years post-operatively.

Conclusion: Endovascular graft suprarenal bare metal stent separation demands a high level of awareness. A better understanding of the involved failure mechanisms and associated risk factors is required to further optimise EVAR follow up protocols.

Keywords: Aortic aneurysm; Device failure; Endovascular aneurysm repair; Stent graft; Suprarenal fixation.

PubMed Disclaimer

Figures

Figure 1
Figure 1
Computed tomography angiogram (sagittal plane) of a 78 year old male patient with abdominal aortic aneurysm showing separation (white arrow) of the suprarenal bare metal stent (∗) from the graft main body (§) after endovascular aneurysm repair.
Figure 2
Figure 2
Angiography (coronal plane) of a 78 year old male patient with abdominal aortic aneurysm. (A) The failed endovascular stent graft before relining. (B) The failed endovascular stent graft after relining showing patent renal arteries and iliac limbs.
Figure 3
Figure 3
Computed tomography angiogram (coronal plane) of a 74 year old male patient with abdominal aortic aneurysm showing endovascular graft suprarenal bare metal stent separation (white arrow).
figs1
figs1
See this image and copyright information in PMC

References

    1. Yokoyama Y., Kuno T., Takagi H. Meta-analysis of phase-specific survival after elective endovascular versus surgical repair of abdominal aortic aneurysm from randomized controlled trials and propensity score-matched studies. J Vasc Surg. 2020;72:1464–1472. - PubMed
    1. Hahl T., Protto S., Järvenpää V., Uurto I., Väärämäki S., Suominen V. Long-term outcomes of endovascular aneurysm repair according to instructions for use adherence status. J Vasc Surg. 2022;76:699–706. - PubMed
    1. Zayed H.A., Bell R.E., Clough R.E., Thomas S., Sabharwal T., Reidy J.F., et al. Results of endovascular repair of abdominal aortic aneurysms with an unfavorable proximal neck using large stent-grafts. Cardiovasc Intervent Radiol. 2009;32:1161–1164. - PubMed
    1. Greenberg R.K., Chuter T.A.M., Cambria R.P., Sternbergh W.C., Fearnot N.E. Zenith abdominal aortic aneurysm endovascular graft. J Vasc Surg. 2008;48:1–9. - PubMed
    1. Abbruzzese T.A., Kwolek C.J., Brewster D.C., Chung T.K., Kang J., Conrad M.F., et al. Outcomes following endovascular abdominal aortic aneurysm repair (EVAR): an anatomic and device-specific analysis. J Vasc Surg. 2008;48:19–28. - PubMed
