. 2023 Aug 22;8(35):31962-31971.
doi: 10.1021/acsomega.3c03776. eCollection 2023 Sep 5.

Novel Enzymatic Biosensor Utilizing a MoS2/MoO3 Nanohybrid for the Electrochemical Detection of Xanthine in Fish Meat

Prateek Sharma  1 , Deeksha Thakur  2 , Devendra Kumar  2
Affiliations

Novel Enzymatic Biosensor Utilizing a MoS2/MoO3 Nanohybrid for the Electrochemical Detection of Xanthine in Fish Meat

Prateek Sharma et al. ACS Omega. .

Abstract

A rapid, reliable, and user-friendly electrochemical sensor was developed for the detection of xanthine (Xn), an important biomarker of food quality. The developed sensor is based on a nanocomposite comprised of molybdenum disulfide-molybdenum trioxide (MoS2/MoO3) and synthesized using a single-pot hydrothermal method. Structural analysis of the MoS2/MoO3 nanocomposite was conducted using X-ray diffraction (XRD) and Raman spectroscopy, while its compositional properties were evaluated through X-ray photoelectron spectroscopy (XPS). Morphological features were observed using scanning electron microscopy (SEM) and transmission electron microscopy (TEM). Two-dimensional (2D) MoS2 offers advantages such as a high surface-to-volume ratio, biocompatibility, and strong light-matter interaction, whereas MoO3 serves as an effective electron transfer mediator and exhibits excellent stability in aqueous environments. The enzymatic biosensor derived from this nanocomposite demonstrates remarkable cyclic stability and a low limit of detection of 64 nM. It enables rapid, reproducible, specific, and reproducible detection over 10 cycles while maintaining a shelf life of more than 5 weeks. These findings highlight the potential of our proposed approach for the development of early detection devices for Xn.

PubMed Disclaimer

Conflict of interest statement

The authors declare no competing financial interest.

Figures

Figure 1
Figure 1
Scheme describing the fabrication of the MoS2/MoO3 nanosheet-based enzymatic biosensor.
Figure 2
Figure 2
Raman spectrum of MoS2/MoO3 nanosheets; the inset shows the characteristic bands for MoS2 nanosheets.
Figure 3
Figure 3
XPS spectra of (a) MoS2/MoO3 nanosheets, (b) XPS map of the Mo 3d element, (c) XPS map of the S 2s element, and (d) XPS map of O 1s.
Figure 4
Figure 4
SEM images (a, b), EDX analysis (c), and elemental mapping of the components (d–f) for MoS2/MoO3 nanosheets.
Figure 5
Figure 5
TEM images at different resolutions: (a–c) SAED patterns of the synthesized MoS2/MoO3 nanosheets.
Figure 6
Figure 6
(a) EIS curves and (b) CV curves of prepared MoS2/ITO and XOD/MoS2/MoO3/ITO electrodes.
Figure 7
Figure 7
(a) CV at different scan rates, (b) anodic and cathodic peak current, and (c) anodic and cathodic peak voltage of the MoS2/MoO3/XOD/ITO electrode.
Figure 8
Figure 8
(a) DPV studies showing the current response of the MoS2/MoO3/XOD/ITO electrode and (b) current calibration plot with increasing concentration of Xn.
Figure 9
Figure 9
DPV studies of the real sample from fish showing the current response of the XOD/MoS2/MoO3/ITO electrode with increasing concentration of Xn.
Figure 10
Figure 10
(a) Specificity and (b) reproducibility tests of the XOD/MoS2/MoO3/ITO electrode for Xn detection in the fish sample.
Figure 11
Figure 11
(a) Reusability tests conducted upto 10 cycles and (b) shelf-life study of upto 5 weeks of the fabricated enzymatic biosensor.
