Redefining Foot Symptoms in a Kidney-Pancreas-Transplanted Type 1 Diabetic Patient: Challenging the Conventional Charcot Foot Diagnosis

Abstract

BACKGROUND Acute Charcot foot can be difficult to diagnose, especially because of other alternate diagnoses that can mimic this condition, particularly stress fracture and acute bone and joint infections, which are 2 conditions that require immediate management. Here, we present the case of a patient who received kidney-pancreas-transplantation for type 1 diabetes mellitus, who consulted for right foot pain after walking. CASE REPORT Our patient was a 47-year-old man who had benefited from a kidney-pancreas transplantation in 2014 for type 1 diabetes and terminal kidney failure and was recently followed for a right foot plantar ulcer that was fully healed. He later presented for right foot pain after walking. Clinical examination showed a red, swollen, and warm foot. Blood test results were unremarkable. Imaging (X-ray/MRI) revealed features compatible with acute Charcot foot. The management consisted of prompt right-foot offloading followed by physiotherapy and adapted orthopedic insoles. CONCLUSIONS This case shows the successful treatment of an active phase of Charcot foot, which avoided the classic transition to chronic Charcot foot with severe osteoarticular destruction. Arguments were developed to rule out other possible diagnoses. The underlying mechanisms of Charcot foot in diabetic patients are related to the neurological and micro-vascular complications induced by poor glycemic control, but the mechanisms are unclear. This case report may help clinicians to better understand and consider another less known and less frequent diagnosis when faced with these clinical features.

Figure 1.

Clinical presentation. Picture of the patient’s feet put next to each other to show the swollen red right foot compared to the healthy left foot.

Figure 2.

Right foot radiography. Sagittal incidence, where we can see vascular calcifications along with talonavicular osteoarthritis with no suggestion of Charcot foot.

Figure 3.

(A-C) MRI of the right foot with different incidences showing multiple fractures (see text) with associated mechanical overload bone edema typical of a bone stress fracture.
