. 2024 Feb 15;24(4):1253.
doi: 10.3390/s24041253.

An Optical Frequency Domain Reflectometer's (OFDR) Performance Improvement via Empirical Mode Decomposition (EMD) and Frequency Filtration for Smart Sensing

Maxim E Belokrylov  1 , Dmitry A Kambur  1   2 , Yuri A Konstantinov  1 , D Claude  1 , Fedor L Barkov  1
Affiliations

An Optical Frequency Domain Reflectometer's (OFDR) Performance Improvement via Empirical Mode Decomposition (EMD) and Frequency Filtration for Smart Sensing

Maxim E Belokrylov et al. Sensors (Basel). .

Abstract

We describe a method for reducing the cost of optical frequency domain reflectometer (OFDR) hardware by replacing two reference channels, including an auxiliary interferometer and a gas cell, with a single channel. To extract useful information, digital signal processing methods were used: digital frequency filtering, as well as empirical mode decomposition. It is shown that the presented method helps to avoid the use of an unnecessary analog-to-digital converter and photodetector, while the OFDR trace is restored by the equal frequency resampling (EFR) algorithm without loss of high resolution and with good measurement repeatability.

Keywords: OFDR; auxiliary interferometer; empirical mode decomposition; gas cell; optical frequency domain reflectometry; optical measurements.

PubMed Disclaimer

Conflict of interest statement

The authors declare no conflicts of interest.

Figures

Figure 1
Figure 1
Smart city monitoring concepts: pointwise and distributed ones.
Figure 2
Figure 2
Experimental setup 1.
Figure 3
Figure 3
Recording of the gas cell channel in time.
Figure 4
Figure 4
Experimental setup 2.
Figure 5
Figure 5
Data received from the combined reference channel of setup 2: (a) complete data set; (b) one of the gas cell peaks enlarged.
Figure 6
Figure 6
Data processing scheme: (a) a fragment of an algorithm with empirical modes circled in blue, excluding residual one (b).
Figure 6
Figure 6
Data processing scheme: (a) a fragment of an algorithm with empirical modes circled in blue, excluding residual one (b).
Figure 7
Figure 7
(a) The IMFs (1–3) of the signal. X-axis—normalized amplitude; Y-axis—time (samples). (b) The IMFs (4–7) of the signal. X-axis—normalized amplitude; Y-axis—time (samples). (c) The IMFs (8–11) of the signal. X-axis—normalized amplitude; Y-axis—time (samples). (d) The IMFs (12–14) of the signal. X-axis—normalized amplitude; Y-axis—time (samples).
Figure 7
Figure 7
(a) The IMFs (1–3) of the signal. X-axis—normalized amplitude; Y-axis—time (samples). (b) The IMFs (4–7) of the signal. X-axis—normalized amplitude; Y-axis—time (samples). (c) The IMFs (8–11) of the signal. X-axis—normalized amplitude; Y-axis—time (samples). (d) The IMFs (12–14) of the signal. X-axis—normalized amplitude; Y-axis—time (samples).
Figure 8
Figure 8
Demonstration of the need to use AUX in OFDR setup.
Figure 9
Figure 9
The OFDR traces reconstructed using AUX, but without the gas cell.
Figure 10
Figure 10
The OFDR traces reconstructed using AUX and GC (for empirical mode decomposition).
