Case Reports
. 2024 May 3;19(8):2996-3000.
doi: 10.1016/j.radcr.2024.04.007. eCollection 2024 Aug.

Spontaneous ilio-iliac arteriovenous fistula: A rare complication of aorto-iliac aneurysm

Fatima Zohra Benbrahim  1 , Majda Ankri  1 , Asmae Fariyou  1 , Omar El Aoufir  1 , Fatima Zahra Laamrani  1 , Jroundi Laila  1
Affiliations
Case Reports

Spontaneous ilio-iliac arteriovenous fistula: A rare complication of aorto-iliac aneurysm

Fatima Zohra Benbrahim et al. Radiol Case Rep. .

Abstract

Ilio-iliac arteriovenous fistula is an unusual complication of aorto-iliac aneurysms that can occur spontaneously, traumatically or iatrogenically. The typical clinical presentation includes the characteristic triad of high-output heart failure, a pulsatile abdominal mass with unilateral limb ischemia, or signs of venous congestion. We describe a rare case of spontaneous rupture of an aortoiliac aneurysm into the left common iliac vein of a 65-year-old man, easily diagnosed by angiography. We highlight here the angiographic findings of the ilio-iliac fistula, which was the means of diagnosis in this presentation, especially in patients with atypical clinical features at the outset, and we report the difficulties in choosing the optimal vascular approach.

Keywords: Aneurysm; Arteriovenous fistula; CTA (Angiography); Iliac artery; Iliac vein.

PubMed Disclaimer

Figures

Fig 1
Fig. 1
CT Angiographic at arterial phase in axial section showing dilatation with simultaneous opacification of IVC and aorta in arterial phase.
Fig 2
Fig. 2
CT Angiographic images at arterial phase in axial section (A) and coronal MIP reconstruction (B) showing an aorto-biliac aneurysm with communication between the right common iliac artery and the left common iliac vein: arteriovenous fistula (yellow star). Note the retrograde enhancement of the IVC.
Fig 3:
Fig. 3
3D reconstructions, showing aneurysmal dilatation of the sub-renal aorta and iliac arteries with visualization of the ilio-Iliac fistula (red arrow).
See this image and copyright information in PMC

References

    1. Nordon IM, Hinchliffe RJ, Loftus IM, Thompson MM. Pathophysiology and epidemiology of abdominal aortic aneurysms. Nat Rev Cardiol. 2011;8(2):92–102. - PubMed
    1. Na SJ, Koh YS, Kim TH, Park SC, Shin WS, Chun HJ, et al. Iliocaval fistula presenting with paradoxical pulmonary embolism combined with high-output heart failure successfully treated by endovascular stent-graft repair: case report. J Korean Med Sci. 2014;29(2):296–300. - PMC - PubMed
    1. Lim RP, Stella DL, Dowling RJ, Campbell WA, Hebbard GS. Iliocaval arteriovenous fistula presenting with multiple organ failure. Australas Radiol. 2006;50(4):381–385. - PubMed
    1. Duppler DW, Herbert WE, Dillihunt RC, Ray FS. Primary arteriovenous fistulas of the abdomen. Arch Surg. 1985;120:786–790. - PubMed
    1. Alexander JJ, Imbembo AL. Aorto-vena cava fistula. Surgery. 1989;105:1–12. - PubMed
