. 2024 Jun 14;30(2):98-102.
doi: 10.4103/meajo.meajo_7_23. eCollection 2023 Apr-Jun.

Radiopathological Correlation in Orbital Lesions

Bipasha Mukherjee  1 , Varsha Backiavathy  1 , C Umadevi  1 , Olma V Noronha  2
Affiliations

Radiopathological Correlation in Orbital Lesions

Bipasha Mukherjee et al. Middle East Afr J Ophthalmol. .

Abstract

Purpose: The objective is to analyze the radiological diagnosis of orbital lesions and their correlation with the final histopathological findings. We compared the initial reports by extramural radiologists and an in-house radiologist specialized in orbital imaging to evaluate the diagnostic accuracy in the interpretation of orbital imaging.

Methods: This was a retrospective chart review of forty patients referred to a Tertiary Eye Care Center in South India over a period of 7 years. These patients already had their imaging done elsewhere. The imaging was re-evaluated by an in-house radiologist. The radiological findings were correlated with the histopathological diagnosis. The diagnostic accuracy between the two radiologists was compared. The sensitivity, specificity, positive predictive value (PPV), and negative predictive value in differentiating malignant from benign lesions were calculated in both groups. The sensitivity and PPV of the radiological diagnosis for neoplastic and inflammatory lesions in both groups were analyzed.

Results: The accuracy in differentiating malignant from benign and inflammatory lesions by our in-house radiologist and extramural radiologists was 95% (κ = 0.9 [0.764, 0.997]) and 50% (κ = 0.036 [-0.160, 0.232]), respectively. The sensitivity and PPV of the radiological diagnosis by our in-house radiologist were 93.31% and 100% for benign lesions and 95.24% and 95.24% for malignant lesions. On the contrary, reports from the extramural radiologists showed a sensitivity and PPV of 76.92% and 66.67% for benign lesions and 14.28% and 60% for malignant lesions.

Conclusion: A high radiological diagnostic accuracy is possible when analyzed by radiologists experienced in orbital imaging.

Keywords: Imaging; orbit; radiopathological correlation.

PubMed Disclaimer

Conflict of interest statement

There are no conflicts of interest.

Figures

Figure 1
Figure 1
Homogenous orbital masses moulding to the globe in the right extraconal space (a and b) and left intraconal space indicated by an arrow (c and d) suggestive of lymphoproliferative lesion, reported elsewhere as haemangioma and idiopathic orbital inflammatory disease by a radiologist ( histopathological examination revealed lymphoma)
Figure 2
Figure 2
Magnetic resonance imaging axial sections and diffusion-weighted imaging of bilateral lymphoproliferative disease (a and b), right pleomorphic adenoma (c and d), left adenoid cystic carcinoma (e and f) of lacrimal gland. Adenoid cystic carcinoma shows diffusion restriction higher than pleomorphic adenoma but lower than lymphoma
See this image and copyright information in PMC

References

    1. Purohit BS, Vargas MI, Ailianou A, Merlini L, Poletti PA, Platon A, et al. Orbital tumours and tumour-like lesions: Exploring the armamentarium of multiparametric imaging. Insights Imaging. 2016;7:43–68. - PMC - PubMed
    1. Custer PL, Kent TL. Pitfalls of ophthalmic radiographic imaging. Curr Opin Ophthalmol. 2014;25:432–5. - PubMed
    1. Koukkoulli A, Pilling JD, Patatas K, El-Hindy N, Chang B, Kalantzis G. How accurate is the clinical and radiological evaluation of orbital lesions in comparison to surgical orbital biopsy? Eye (Lond) 2018;32:1329–33. - PMC - PubMed
    1. Bacorn C, Gokoffski KK, Lin LK. Clinical correlation recommended: Accuracy of clinician versus radiologic interpretation of the imaging of orbital lesions. Orbit. 2021;40:133–7. - PubMed
    1. Ben Simon GJ, Annunziata CC, Fink J, Villablanca P, McCann JD, Goldberg RA. Rethinking orbital imaging establishing guidelines for interpreting orbital imaging studies and evaluating their predictive value in patients with orbital tumors. Ophthalmology. 2005;112:2196–207. - PubMed
