. 2024 Jul 27;10(1):61.
doi: 10.1038/s41405-024-00247-y.

Endodontic radiography - what's displaying the radiograph? The yield of commercial computer screens vs. DICOM calibrated medical screens in endodontic radiography

Idan Stiklaru  1   2 , Ella Lalum  3   4 , Avi Levin  3   4 , Avi Shemesh  3   4 , Hadas Azizi  3   4 , Nirit Yavnai  5 , Joe Ben Itzhak  3   4 , Michael Solomonov  3   4
Affiliations

Endodontic radiography - what's displaying the radiograph? The yield of commercial computer screens vs. DICOM calibrated medical screens in endodontic radiography

Idan Stiklaru et al. BDJ Open. .

Abstract

Objective: A comparison between commercial computer screens and DICOM-calibrated medical screens for characterizing anatomy and diagnosing dental pathologies was performed. The aim of this study was to evaluate and compare the ability of each of those screens to identify root apices and widening of the periodontal ligament (PDL) in the posterior maxillary area.

Materials and methods: Digital X-ray images of 53 maxillary molar teeth were examined by means of a commercial computer screen and again two months later with a DICOM screen to compare their ability to help identify and diagnose PDL widening and to locate the root apices of those teeth.

Results: The DICOM screen had a significantly better ability to identify widened PDLs (from 31.4% to 34.8% of the cases compared to 19% to 26.1% for the commercial screens, P < .001), depending upon the observer. The DICOM screen was also significantly superior in depicting the root apices compared to the commercial screens (from 77.4% to 83.6% of the cases compared to 56% to 66.7% for the commercial screens, P < 0.001), depending upon the observer.

Conclusion: DICOM-calibrated medical screens were significantly superior to commercial computer screens for identifying widened PDLs and locating the root apex in the posterior maxillary area.

PubMed Disclaimer

Conflict of interest statement

The authors declare no competing interests.

Figures

Fig. 1
Fig. 1. A periapicl x-ray of tooth #16, in both commercial screen and a diagnostic screen, photographed using a digital camera.
a, b Tooth #16: The PDL of the buccal roots was identified as “widened” when using DS and not “not widened” when using CS (a = CS, b = DS).
Fig. 2
Fig. 2. A periapicl x-ray of tooth #16, in both commercial screen and a diagnostic screen, photographed using a digital camera.
a, b Tooth #16: The root apices were not visible when using the CS, while the DS identified their apices (a = CS, b = DS).
See this image and copyright information in PMC

References

    1. Countryman SC, Melo SL, Belem MD, Haiter-Neto F, Vargas MA, Allareddy V. Performance of 5 different displays in the detection of artificial incipient and recurrent caries-like lesions. Oral Surg, Oral Med, Oral Pathol Oral Radiol. 2018;125:182–91. 10.1016/j.oooo.2017.11.004 - DOI - PubMed
    1. Kamitani T, Yabuuchi H, Matsuo Y, Setoguchi T, Sakai S, Okafuji T, et al. Diagnostic performance in differentiation of breast lesion on digital mammograms: comparison among hard-copy film, 3-megapixel LCD monitor, and 5-megapixel LCD monitor. Clin Imaging. 2011;35:341–5. 10.1016/j.clinimag.2010.08.015 - DOI - PubMed
    1. Buls N, Shabana W, Verbeek P, Pevenage P, De Mey J. Influence of display quality on radiologists’ performance in the detection of lung nodules on radiographs. Br J Radiol. 2007;80:738–43. 10.1259/bjr/48049509 - DOI - PubMed
    1. Liang Z, Li K, Yang X, Du X, Liu J, Zhao X, et al. ROC analysis for diagnostic accuracy of fracture by using different monitors. J Dig. Imaging. 2006;19:276–8.10.1007/s10278-006-0265-9 - DOI - PMC - PubMed
    1. Krupinski EA, Johnson J, Roehrig H, Nafziger J, Fan J, Lubin J. Use of a human visual system model to predict observer performance with CRT vs LCD display of images. J Digital Imaging. 2004;17:258–63.10.1007/s10278-004-1016-4 - DOI - PMC - PubMed
