. 2024 Oct;53(10):688-703.
doi: 10.1177/03010066241263052. Epub 2024 Aug 1.

Body image at the trunk: An investigation into externally referenced width perception and picture mapping

Simon Pratt  1 , Benedict M Wand  1 , Dana A Hince  2 , Mervyn J Travers  1 , Lee Schneider  1 , Sara Kelly  1 , William Gibson  1
Affiliations

Body image at the trunk: An investigation into externally referenced width perception and picture mapping

Simon Pratt et al. Perception. 2024 Oct.

Abstract

Body image is a conscious representation of the body, encompassing how our body feels to us. Body image can be measured in a variety of ways, including metric and depictive measures. This study sought to assess body image at the trunk by investigating, and comparing, a metric and depictive measure. Sixty-nine healthy participants estimated their thorax, waist, and hip width by externally referencing mechanical calipers. Participants were also asked to select the true image of their trunk from a random display of nine images containing the true image and incrementally shrunken or enlarged images. Participants demonstrated evidence of thorax and waist width overestimation in the width perception task, with no evidence for hip misestimation. For the picture mapping task, the majority of participants were inaccurate. In participants who were inaccurate, approximately equal proportions underestimated and overestimated their trunk width. The two tasks were found to be independent of each other. Distortions, or inaccuracies, were apparent in a metric measure, and inaccuracies also present in a depictive measure, of body image at the trunk for healthy participants. An overestimation bias was apparent in the metric, but not depictive, task. No relationship was found between tasks..

Keywords: Body image; body representation; depictive measures; externally referenced width perception; metric measures; template matching.

PubMed Disclaimer

Conflict of interest statement

Declaration of Conflicting InterestsThe authors declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.

Figures

Figure 1.
Figure 1.
Externally referenced width perception task using adjustable calipers.
Figure 2.
Figure 2.
Picture mapping task images as per presented to participants.
Figure 3.
Figure 3.
Picture mapping task: the percentage of participants selecting each image, by image width. The numbers above the bars represent the number of participants selecting each image width.
Figure 4.
Figure 4.
Box and whisker plots of mean body perception index (BPI) (%) verses picture mapping image width (%) selected.
See this image and copyright information in PMC

Similar articles

See all similar articles

References

    1. Ben-Tovim D. I., Whitehead J., Crisp A. H. (1979). A controlled study of the perception of body width in anorexia nervosa. Journal of Psychosomatic Research, 23(4), 267–272. 10.1016/0022-3999(79)90029-1 - DOI - PubMed
    1. D'Amour S., Harris L. R. (2020). The perceived size of the implicit representation of the dorsum and palm of the hand. PLoS ONE, 15(3), e0230624. 10.1371/journal.pone.0230624 - DOI - PMC - PubMed
    1. de Vet H. C., Terwee C. B., Knol D. L., Bouter L. M. (2006). When to use agreement versus reliability measures. Journal of Clinical Epidemiology, 59(10), 1033–1039. 10.1016/j.jclinepi.2005.10.015 - DOI - PubMed
    1. de Vignemont F. (2010). Body schema and body image—Pros and cons. Neuropsychologia, 48(3), 669–680. 10.1016/j.neuropsychologia.2009.09.022 - DOI - PubMed
    1. Dolan B. M., Birtchnell S. A., Lacey J. H. (1987). Body image distortion in non-eating disordered women and men. Journal of Psychosomatic Research, 31(4), 513–520. 10.1016/0022-3999(87)90009-2 - DOI - PubMed
