Case Reports
. 2024 Dec 6;20(2):1273-1276.
doi: 10.1016/j.radcr.2024.11.026. eCollection 2025 Feb.

Large tumor thrombus extending into the right atrium through the inferior vena cava due to hepatocellular carcinoma: A case report

Georgios Benetos  1   2 , Angeliki Vakka  3 , Eirini Solomou  1 , Vasiliki Katsi  4 , Konstantinos Tsioufis  1 , Konstantinos Toutouzas  1
Affiliations
Case Reports

Large tumor thrombus extending into the right atrium through the inferior vena cava due to hepatocellular carcinoma: A case report

Georgios Benetos et al. Radiol Case Rep. .

Abstract

This is a case report of a 54-year-old patient with hepatocellular cancer under palliative chemotherapy who admitted with dyspnea on minimal exertion and peripheral oedema over the past 5 days. Echocardiogram revealed a large echogenic mass in the right atrial cavity which did not enhance with intravenous echo contrast agent, and a distended inferior vena cava (IVC) which was occluded by echogenic material with no signs of flow. To distinguish with accuracy if the thrombus was a bland or tumor thrombus, contrast-enhanced Computed Tomography (CT) was performed. CT Pulmonary Angiography and abdominal contrast-enhanced CT showed a distended and occluded IVC by a mass that extended to the right atrium and enhanced with intravenous contrast agent, and thus the mass was considered as a tumor thrombus. Due to the impaired performance status and liver function of the patient, supportive treatment was preferred instead of a surgical or radiological intervention. Large tumor thrombus extending into the right atrium through the inferior vena cava due to hepatocellular carcinoma has a rare incidence and is associated with a poor prognosis.

Keywords: Case report; Hepatocellular carcinoma; Right atrium; Tumor thrombus.

PubMed Disclaimer

Figures

Fig 1:
Fig. 1
(A) Transthoracic echocardiography revealed a large echogenic mass in the right atrium (red arrow), (B) Contrast echocardiography showed that the mass in the Fig. 1A does not enhance with intravenous contrast agent, indicating that this mass may be a bland thrombus (red arrow), (C) Inferior vena cava appears distended and occluded with echogenic material and no signs of flow (between the red arrows) in the transthoracic echocardiogram.
Fig 2:
Fig. 2
(A) Computed tomography pulmonary angiography before contrast enhancement showed that the mass extends from inferior vena cava to the right atrium, (B) Computed tomography pulmonary angiography after contrast enhancement revealed that this mass enhances with contrast agent, indicating that this mass may be a tumor thrombus, (C) Sagittal view showing the tumor thrombus extending from inferior vena cava to the right atrium, (D) Coronal view showing the tumor thrombus extending from inferior vena cava to the right atrium.
See this image and copyright information in PMC

Similar articles

See all similar articles

References

    1. Bray F., Ferlay J., Soerjomataram I., Siegel R.L., Torre L.A., Jemal A. Global cancer statistics 2018: GLOBOCAN estimates of incidence and mortality worldwide for 36 cancers in 185 countries. CA Cancer J Clin. 2018;68(6):394–424. doi: 10.3322/CAAC.21492. - DOI - PubMed
    1. Llovet J.M., Kelley R.K., Villanueva A., Singal A.G., Pikarsky E., Roayaie S., et al. Hepatocellular carcinoma. Nat Rev Dis Primers. 2021;7(1):1–28. doi: 10.1038/s41572-020-00240-3. - DOI - PubMed
    1. Reig M., Forner A., Rimola J., Ferrer-Fàbrega J., Burrel M., Garcia-Criado Á., et al. BCLC strategy for prognosis prediction and treatment recommendation: the 2022 update. J Hepatol. 2022;76(3):681–693. doi: 10.1016/J.JHEP.2021.11.018. - DOI - PMC - PubMed
    1. Lee I.J., Jin Wook C., Kim H.C., Hu Yin Y., Young H.S., Ung Bae J., et al. Extrahepatic collateral artery supply to the tumor thrombi of hepatocellular carcinoma invading inferior vena cava: the prevalence and determinant factors. J Vasc Interv Radiol. 2009;20(1):22–29. doi: 10.1016/J.JVIR.2008.09.030. - DOI - PubMed
    1. Wang Y., Yuan L., Ge R.L., Sun Y., Wei G. Survival benefit of surgical treatment for hepatocellular carcinoma with inferior vena cava/right atrium tumor thrombus: results of a retrospective cohort study. Ann Surg Oncol. 2013;20(3):914–922. doi: 10.1245/S10434-012-2646-2. - DOI - PubMed
