Review
. 2024 Dec 17;15(12):1504.
doi: 10.3390/mi15121504.

MOSFET-Based Voltage Reference Circuits in the Last Decade: A Review

Elisabetta Moisello  1 , Edoardo Bonizzoni  1 , Piero Malcovati  1
Affiliations
Review

MOSFET-Based Voltage Reference Circuits in the Last Decade: A Review

Elisabetta Moisello et al. Micromachines (Basel). .

Abstract

Voltage reference circuits are a basic building block in most integrated microsystems, covering a wide spectrum of applications. Hence, they constitute a subject of great interest for the entire microelectronics community. MOSFET-based solutions, in particular, have emerged as the implementation of choice for realizing voltage reference circuits, given the supply voltage scaling and the ever-lower power consumption specifications in various applications. For these reasons, this paper aims to review MOSFET-based voltage reference circuits, illustrating their principles of operation, as well as presenting a detailed overview of the state-of-the-art, in order to paint an accurate picture of the encountered challenges and proposed solutions found in the field in the last decade, thus providing a starting point for future research in the field.

Keywords: BJT; CMOS; MOSFET; PSR; bandgap; line sensitivity; low power; low voltage; microelectronics; temperature coefficient; temperature compensation; voltage reference.

PubMed Disclaimer

Conflict of interest statement

The authors declare no conflicts of interest.

Figures

Figure 1
Figure 1
Schematic representation of a standard current-mode bandgap reference circuit.
Figure 2
Figure 2
Schematic representation of a bandgap-like MOSFET-based reference circuit.
Figure 3
Figure 3
Schematic representation of a generic threshold voltage-based MOSFET reference circuit.
Figure 4
Figure 4
Graphical representation of a transistor ZTC point.
Figure 5
Figure 5
Schematic representation of a self-cascode MOSFET (SCM).
Figure 6
Figure 6
Schematic representation of a few 2T voltage reference topologies: (a) employs thin-oxide and native devices, (b) uses thick-oxide and thin-oxide devices, (c) relies on same-type devices, while (d) uses NMOS and PMOS devices.
Figure 7
Figure 7
Schematic representation of a threshold voltage-based reference circuit employing body biasing.
Figure 8
Figure 8
Graphical summary of the TC of the reported works as a function of power consumption. The representation is in logarithmic scale.
See this image and copyright information in PMC

References

    1. Dei M., Aymerich J., Piotto M., Bruschi P., del Campo F.J., Serra-Graells F. CMOS Interfaces for Internet-of-Wearables Electrochemical Sensors: Trends and Challenges. Electronics. 2019;8:150. doi: 10.3390/electronics8020150. - DOI
    1. Colbach L., Jang T., Ji Y. A 21.4 pW Subthreshold Voltage Reference with 0.020%/V Line Sensitivity Using DIBL Compensation. Sensors. 2023;23:1862. doi: 10.3390/s23041862. - DOI - PMC - PubMed
    1. Huang Y., Luo Y., Zeng Y. Picowatt Dual-Output Voltage Reference Based on Leakage Current Compensation and Diode-Connected Voltage Divider. Electronics. 2024;13:3533. doi: 10.3390/electronics13173533. - DOI
    1. Azimi M., Habibi M., Crovetti P. A Two-Stage Sub-Threshold Voltage Reference Generator Using Body Bias Curvature Compensation for Improved Temperature Coefficient. Electronics. 2024;13:1390. doi: 10.3390/electronics13071390. - DOI
    1. Banba H., Shiga H., Umezawa A., Miyaba T., Tanzawa T., Atsumi S., Sakui K. A CMOS bandgap reference circuit with sub-1-V operation. IEEE J. Solid-State Circuits. 1999;34:670–674. doi: 10.1109/4.760378. - DOI
