. 2025 Apr 9;9(4):1282-1285.
doi: 10.1016/j.jseint.2025.03.013. eCollection 2025 Jul.

Distance of the radial nerve from distal interlocking screws in long-stem reverse shoulder arthroplasty: a cadaveric analysis

Ethan R Harris  1 , Steve S Li  1 , Seyedeh Zahra Mousavi  1 , Prasenjit Saha  1 , Mark A Haft  1 , Miriam D Weisberg-Tannenbaum  1 , Umasuthan Srikumaran  1
Affiliations

Distance of the radial nerve from distal interlocking screws in long-stem reverse shoulder arthroplasty: a cadaveric analysis

Ethan R Harris et al. JSES Int. .

Abstract

Long-stem reverse total shoulder arthroplasty (rTSA) with interlocking screws is indicated for trauma and revision shoulder arthroplasty and enables fixation of the prosthesis without cement or a plate while maintaining rotational stability. We investigated the distance of the radial nerve from the distal interlocking screws of the long-stem rTSA to recommend a safe approach in placement of this prosthesis. The 3 distal 4.5-mm cortical interlocking screws of a 200-mm long-stem rTSA (FX Shoulder) were inserted with the humeral prosthesis at 0° and 20° of retroversion in 8 cadaveric specimens. A curvilinear incision from the anterolateral cubital fossa extending superolaterally along the humerus was made to expose the radial nerve between the brachialis and brachioradialis. The shortest distance from each screw to the radial nerve at 90° of elbow flexion was measured, and mean and standard deviations were calculated. At 0° of retroversion of the humeral prosthesis, the most distal 3 screws were a mean 9.5, 4.2, and 0.93 mm away from the radial nerve, respectively, whereas 20° of retroversion yielded mean screw-to-radial-nerve distances of 20, 15, and 8.7 mm, respectively. The mean distance to the radial nerve increased with increasing retroversion of the stem. We recommend using at least 20° of retroversion and making an incision anteriorly with careful retraction of soft tissues posteriorly on the humeral shaft to enable direct visualization during placement of the most distal interlocking screws to protect neurovascular structures.

Keywords: Cadaveric study; Humeral interlocking screws; Long-stem shoulder prosthesis; Periprosthetic fracture; Radial nerve; Retroversion; Reverse shoulder arthroplasty.

PubMed Disclaimer

Figures

Figure 1
Figure 1
Radiographs showing a 200-mm long-stem reverse shoulder arthroplasty prosthesis with 4 interlocking screws. (A) Anteroposterior view taken immediately after reverse shoulder arthroplasty for fracture. (B) Grashey view taken 4 months postoperatively, showing interval healing. Screw hole 1 and screws 2-5 are labeled.
Figure 2
Figure 2
Photographs showing (A) drilling of the hole for screw 5 in long-stem reverse shoulder arthroplasty at 20° of retroversion; and (B) the radial nerve (RN) coursing between the brachioradialis and brachialis, with screws 3 and 4 labeled. Screw 5 is deep to the brachialis.
See this image and copyright information in PMC

References

    1. Berton A., Longo U.G., Gulotta L.V., De Salvatore S., Piergentili I., Calabrese G., et al. Humeral and glenoid version in reverse total shoulder arthroplasty: a systematic review. J Clin Med. 2022;11:7416. doi: 10.3390/jcm11247416. - DOI - PMC - PubMed
    1. Boileau P., Raynier J.-L., Chelli M., Gonzalez J.-F., Galvin J.W. Reverse shoulder-allograft prosthesis composite, with or without tendon transfer, for the treatment of severe proximal humeral bone loss. J Shoulder Elbow Surg. 2020;29:e401–e415. doi: 10.1016/j.jse.2020.03.016. - DOI - PubMed
    1. Carlan D., Pratt J., Patterson J.M.M., Weiland A.J., Boyer M.I., Gelberman R.H. The radial nerve in the brachium: an anatomic study in human cadavers. J Hand Surg Am. 2007;32:1177–1182. doi: 10.1016/j.jhsa.2006.07.001. - DOI - PubMed
    1. Chen W.A., Luo T.D., Wigton M.D., Li Z. Anatomical factors contributing to radial nerve excursion at the brachium: a cadaveric study. J Hand Surg Am. 2018;43:288.e1–288.e7. doi: 10.1016/j.jhsa.2017.09.023. - DOI - PubMed
    1. Greiner F., Kaiser G., Kleiner A., Brugger J., Aldrian S., Windhager R., et al. Distal locking technique affects the rate of iatrogenic radial nerve palsy in intramedullary nailing of humeral shaft fractures. Arch Orthop Trauma Surg. 2023;143:4117–4123. doi: 10.1007/s00402-022-04665-1. - DOI - PMC - PubMed
